A-B 1394-SJT05-C-RL
A-B 1394-SJT05-C-RL Product Description
Product Overview
A-B 1394-SJT05-C-RL is a 5-bit encoder with an encoder ring used for measuring the position and speed of motors or other rotating equipment in industrial applications. It belongs to the Allen Bradley Kinetix series encoder and has the following characteristics:
High precision: Provides a resolution of 0.01 degrees, enabling precise measurements.
High reliability: Adopting a sturdy and durable design, it can withstand harsh environmental conditions.
Quick response: With a fast response time, real-time position and speed measurements can be achieved.
Easy to install: The encoder ring can be easily installed onto the motor shaft.

Product parameters

Model:1394-SJT05-C-RL

Resolution:0.01 degrees

Pulse count:5000 pulses per revolution

Power supply voltage:24 VDC

Output signal:RS-422

Working temperature:-40°C to+85°C(-40°F to+185°F)

Protection level:IP67

Size:90 x 60 x 30 mm(3.5 x 2.4 x 1.2 in)

Weight:0.5 kg(1.1 lbs)

Product application

The A-B 1394-SJT05-C-RL encoder can be widely used in various industrial automation systems,including:

Servo motor control:Measure the position and speed of the motor to achieve precise servo control.

Robot:Measure the joint position and velocity of the robot to achieve precise motion control.

Packaging Machinery:Measuring conveyor belt speed to achieve precise material handling and packaging.

Printing Machinery:Measuring the speed of printing rollers to achieve precise printing control.
