ABB

Model: CP800 Display screen size: 7 inches Resolution: 800 x 480 Touch screen: capacitive type Interface: USB RS-232/485、Ethernet Power supply voltage: 24 VDC

/

ABB

Model: HC800 Power range: 0.75 kW to 315 kW Voltage range: 380 V to 480 V Frequency range: 0.5 Hz to 590 Hz Control method: Vector control Protection functions: overcurrent protection, overvoltage protection, overload protection, short circuit protection

/

ABB

Model: CI860K01 3BSE032444R1 Power supply voltage: 24 VDC Power consumption: 2 W Communication speed: 31.25 kbps... 2 Mbps Working temperature: -25 ° C... 70 ° C Size: 125 x 75 x 30 mm Weight: 0.5 kg

/

ABB

High performance: rated current up to 40A, short-circuit breaking capacity up to 25kA High reliability: using reliable mechanical structures and contact materials Scalability: Supports multiple attachment extensions to meet different application needs Easy to install: using standard guide rail installation method Product parameters Rated voltage: 230/400V Rated current: 40A Short circuit breaking capacity: 25kA Working temperature: -25 ℃~70 ℃ Protection level: IP20

/

ABB

Model: DSSR122 4899001-NK Voltage: 24 VDC Power consumption: 2 W Communication speed: 31.25 kbps... 2 Mbps Working temperature: -25 ° C... 70 ° C Size: 125 x 75 x 30 mm Weight: 0.5 kg

/

ABB

Model: PM511V16 3BSE011181R1 Function: Processor module Application: Variable frequency drive control Central Processing Unit: Freescale PowerPC MPC5200B Main frequency: 400 MHz Memory: 256MB Storage space: 2GB Network: VxWorks Interface: RS485, Ethernet Size: 233mm x 170mm x 45mm Weight: 500 grams

/

ABB

Interface type S800 I/O module to AF100 control system The speed can reach 10 Mbps Stimulate 100 to 240 volts AC Frequency 50/60 Hz Working temperature range -10 ° C to+55 ° C Storage temperature range -20 ℃ to+70 ℃ Protective equipment IP67 90x60x115mm Weight 0.5 kilograms

/

ABB

Model: DSTA131 Series: S100 Connection type: AI board and S100 series controller Analog I/O points: 32 (16 input/output each) Number of digital I/O points: 16 (8 input/output each) Power supply voltage: 24 V DC Working temperature: -20 ° C to 55 ° C Protection level: IP20

/

ABB

Rated current: 800A Rated voltage: AC 690V Circuit breaking capacity: 40kA Protection level: IP40 Certification standards: IEC, GB, CB

/

ABB

Model: 5SDF1045H0002 Brand: ABB Type: High voltage thyristor module Voltage withstand value: 10.4kV Maximum repetitive peak current: Depending on the specific model Packaging form: PRESS-FIT Working temperature: -40 ℃~+150 ℃

/

ABB

Model: 5SDF0860H0003 Brand: ABB Type: High voltage diode module Voltage withstand value: 6kV Average rectified current: depending on the specific model Packaging form: PRESS-FIT Working temperature: -40 ℃~+150 ℃

/

ABB

Model UNS0122A-P Brand ABB Type digital output submodule Number of materials 8 Output type normally open/normally closed Working voltage 24V DC V Working temperature: 0 ° C to 55 ° C ℃

/
