A-B 1769-IQ16F

A-B 1769-IQ16F series high-speed input module

Product Overview

The 1769-IQ16F AB series is a high-speed input module from the Allen Bradley brand launched by Rockwell Automation,suitable for CompactLogix controllers.This module provides 16 high-speed input channels,supports various digital signals,and has a sampling rate of up to 25 kHz.

Product specifications

Model Description

1769-IQ16F 16 point high-speed input module

series

The 1769-IQ16F AB belongs to the Allen Bradley 1769 I/O expansion module series,which provides various types of input and output functions to meet the various application needs of CompactLogix controllers.

1769-IQ16F

features

High speed sampling:With a sampling rate of 25 kHz,it can capture rapidly changing signals.

High resolution:1 microsecond resolution ensures the accuracy of measurement data.

Multiple suppression options:configurable low-pass filter to eliminate signal noise.

Signal isolation:1500 V RMS signal isolation ensures safety and reliability.

A-B 1769-IQ16F

Product parameters

16 input channels

Final category:Digital signal

Sampling rate 25 kHz

Fruit 1 microsecond

Configurable low-pass filter for filtering

Signal 1500 V root mean square

Power requirement+24V DC,50mA

Working temperature-40°C to+70°C

5%to 95%non condensable impurities

Protective equipment IP20

.80mm x 31mm x 23mm

Weight 120 grams

effect

The 1769-IQ16F AB series is used to convert signals from various digital signal sources into digital signals that can be processed by the CompactLogix controller.This module can be used for various applications,such as:

Motion control:used to control motion equipment such as servo motors and stepper motors.

Encoder interface:used to collect information such as encoder position and speed.

Counting:Used to count pulse signals.

Data collection:used to collect high-speed changing data,such as:

Vibration data

Pressure data

Temperature data

objective

Motion control:used for motion control in various industrial automation applications,such as:

Packaging Machinery

Printing machinery

Sports

Encoder interface:an encoder interface used in various industrial automation applications,such as:

numerical control machine

servo system

Sports

Counting:Used for counting in various industrial automation applications,such as:

Number of production lines

Number of packages

Traffic quantity

Data collection:Used for high-speed data collection in various industrial and scientific applications,such as:

vibration analysis

Testing

temperature measurement

application area

The 1769-IQ16F AB series extensively evaluates various industrial and scientific fields,including:

Mechanical manufacturing

automobile

Food and Food

packing

printing

semiconductor

laboratory

Research
