Product Overview

GE IS200TREGH1B is an excitation bridge interface board designed specifically for GE Mark VI series turbine control systems. As a key component in the system, it is responsible for providing most of the interface functions between the excitation machine control interface board and the excitation machine bridge of the innovative series medium voltage SP drive, thereby achieving precise control of the turbine excitation system

Product Features

Rich interfaces: Provides multiple plug-in connectors that can connect various discrete wired AC and DC inputs to establish voltage feedback. The current feedback operates through the J2 connector and is generated by a DC current splitter connected to the DC output terminal of the excitation bridge

Powerful function: equipped with MOV fuse loss detection function, and providing LED indicator lights and testing points, making it convenient for users to monitor the status and diagnose faults

High reliability: using industrial grade components with good durability and stability

Wide applicability: can be used for 3300V and 6600V versions of drivers

Product parameters

Model: IS200TREGH1B

Series: Mark VI

Function: Exciter bridge interface

Interface type: Multiple plug-in connectors

Voltage level: suitable for 3300V and 6600V drivers

Protection function: MOV fuse loss detection

Indicator lights: Multiple LED indicator lights

Test points: Multiple test points

IS200TREGH1B

Product specifications

Installation method: Install according to system requirements

Environmental requirements: Industrial environment

Certification: Compliant with relevant industry standards

Series

Belonging to the GE Mark VI series, it is part of the GE Speedtronic series of turbine and gas turbine management systems

Features

Rich interfaces: connecting multiple signals

Powerful features: MOV fuse detection, LED indication, testing points

High reliability: industrial grade components

Wide applicability: Suitable for drivers of different voltage levels

Function

Interface conversion: Provide an interface between the excitation machine control interface board and the excitation machine bridge

Signal processing: Processing signals such as voltage and current

Protection function: Detect the status of MOV fuses and protect equipment

Status monitoring: Status monitoring is carried out through LED indicator lights and test points

IS200TREGH1B

Purpose:

Steam turbine control system: used to control the excitation system of the steam turbine

Power system: used for excitation control in power systems

Application Fields

Power industry: power plants, substations, etc

Industrial sector: Industrial enterprises that require the use of steam turbines
