The amplitude sensing servo system consists of five parts: measuring components and signal processing circuits, digital/analog converters, comparators, driving components, and execution components. There are two main differences between it and the phase detection servo system: firstly, its measuring elements work in the amplitude detection mode, and the measuring elements that can be used in the amplitude detection servo system include rotary transformers and induction synchronizers; The second is that the comparator compares digital pulses (rather than phase signals), so there is no need for a reference signal. The two digital pulses can be directly compared in the comparator for the number of pulses.

The measuring components and signal processing circuits detect the mechanical displacement of the workbench and convert it into digital pulses. According to the introduction of the working principle of the sensor in Chapter 11, it can be seen that when the sensor is in amplitude sensing working state, the output voltage u0=Usin (α - θ) sin ω t, that is, the displacement can be determined by measuring the amplitude of u0. In other words, the amplitude Usin (α - θ) of u0 represents the displacement of the worktable. After filtering, amplifying, detecting, and rectifying, this sine signal becomes a DC voltage signal with a direction corresponding to the movement direction of the worktable and an amplitude proportional to the displacement of the worktable. This process is called demodulation, and the demodulated signal is converted into counting pulses by a voltage frequency converter. The number of pulses is proportional to the voltage amplitude and the direction is represented by a symbol trigger.
