Type:Microprocessor-based Control Board

Operating System:RTOS (Real-Time Operating System)

Memory Capacity:128 KB Flash Memory, 32 KB RAM

Processing Speed:60 MHz

Input/Output Ports:16 Digital Inputs, 10 Analog Inputs, 8 Digital Outputs, 4 Analog Outputs

Communication Protocols:Modbus, Ethernet/IP, Profinet

Power Consumption:Max. 15W

Environmental Conditions:Operating Temperature: 0°C to +55°C, Storage Temperature: -40°C to +85°C

Dimensions:104mm x 104mm x 32mm

Weight:0.08kg

    The ABB SNAT7261NBN QCP control board boasts an efficient and compact design, engineered to meet the stringent demands of modern industrial environments. Its robust processor ensures swift execution of complex control algorithms, enhancing operational performance.

    Equipped with a high-speed Ethernet interface, this control board facilitates seamless data exchange with other devices on the network, improving overall system integration and responsiveness.

    With a comprehensive set of 32 digital input channels and 16 digital output channels, it offers versatile connectivity options suitable for a wide range of applications, from process control to machine automation.

    Operated on an RTOS, the control board ensures real-time processing critical for maintaining system stability and reliability, even under demanding conditions.

    Adaptable to various industrial environments, its temperature-resistant design ensures stable operation within a broad range, from cold storage facilities to hot manufacturing plants, without compromising performance.
