Control Power nominal:20 VA

Control Power maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:Approx. 12 in H x 5 in W x 8 in L

Ground Current Input Frequency:20 to 100 Hz

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Weight:Approx. 4.5 kg

Protection Features:Undervoltage auto-restart, Reverse power, Starter failure, KVA demand, KVAR demand, KW demand, Current demand, Backspin detection, Self test/service, Trip counter, Loss of RRTD communications, Broken/open RTD, Short/low temp RTD, Ambient RTD, Acceleration timer, Mechanical jam, and more.

    The GE 369-HI-R-M-0-E Motor Management Relay offers unparalleled protection and control over medium to large motors.

     With its sophisticated built-in metering capabilities and waveform capture, it ensures optimal motor operation and longevity.

     Key features include undervoltage auto-restart, reverse power protection, and self-test/service functions, all aimed at reducing operational disruptions.

     This relay supports a wide range of input voltages and frequencies, making it highly versatile across different industrial environments.

     Its compact design and lightweight make installation straightforward, enhancing ease of use and maintenance.

     The included twelve RTD inputs further elevate its diagnostic capabilities, providing real-time monitoring and predictive maintenance insights.
