Brand:General Electric (GE)

Model:DS3800NHVN1A1A

Type:Motor Excitation Board

Series:Mark IV

Compatibility:For steam and gas turbines

Dimensions:Varies

Weight:Not specified

Operating Voltage:High voltage

Features:Alignment-marked, factory-drilled

Capacitors:Four small yellow capacitors, four metal capacitors, four long black capacitors

    The DS3800NHVN1A1A is a specialized printed circuit board (PCB) designed for the control and management of steam and gas turbines. As a core component in the Mark IV series, it ensures efficient and reliable operation through its high voltage capabilities and robust design.

    This board features an array of capacitors, including four small yellow capacitors, four metal capacitors, and four long black capacitors, enhancing its performance and durability. It is meticulously aligned-marked and factory-drilled in each corner for accurate placement during installation, ensuring seamless integration with existing systems.

    With the capability to monitor critical aspects like fuel and air emissions, the DS3800NHVN1A1A facilitates precise control over turbine operations. Additionally, it automates essential procedures such as startup and shutdown, contributing to increased efficiency and reduced downtime.

    For those requiring technical support or more detailed installation instructions, these resources can typically be found in manuals or data sheets specific to the DS3800NHVN1A1A. General Electric offers comprehensive support for this product, ensuring users have access to the latest technical publications and assistance.
