Brand:Allen Bradley

Model:802R-HFW1

Type:Limit Switch

Sealing:NEMA Sealed

Material:Metal

Actuator:Roller Lever

Operating Force:2.2 lbs

Contact Rating:10A @ 250VAC

Max Switching Voltage:250VAC

Max Switching Current:10A

Number of Poles:1

Number of Throws:1

Electrical Life:1 million cycles

Environmental Protection:NEMA 4X, IP67

Operating Temperature Range:-20°C to 85°C

    The A-B 802R-HFW1 Metal NEMA Sealed Limit Switch is an essential component for any industrial control system requiring accurate position feedback. Its robust metal construction ensures durability and reliability in challenging environments.

    With its NEMA 4X/IP67 rating, this limit switch provides excellent protection against dust, water, and corrosive agents, making it suitable for outdoor and washdown applications.

    The push-to-test/spring-return operation offers a simple yet effective way to monitor position changes, providing a reliable signal for control systems.

    The SPST contact configuration allows for straightforward integration into existing circuits, and its rated current and voltage capabilities make it suitable for a wide range of applications.

    Designed for panel mounting, the switch can be easily installed in control panels and enclosures, ensuring a secure fit and minimizing the risk of accidental dislodgment.
