Manufacturer:ABB

Model:Pressductor PillowBlock Load Cell

Capacity:16 KN (3600 lbs)

Force Measurement Range:Horizontal Force Measurement

Rated Output:2 mV/V

Operating Temperature Range:-40°C to +120°C

Non-Linearity:< ±0.03% FSO

Repeatability:< ±0.02% FSO

Temperature Effect on Zero:< ±0.03% FSO/10°C

Temperature Effect on Span:< ±0.03% FSO/10°C

Input Resistance:350 Ω

Output Resistance:350 Ω

Creep:< ±0.02% FSO/30 min

Safe Overload:200% FSO

Breakdown Overload:300% FSO

Insulation Resistance:> 2000 MΩ @ 50 VDC

Natural Frequency:> 1000 Hz

Material:Stainless Steel

    The ABB Pressductor PillowBlock Load Cell is engineered with high precision to provide accurate measurement capabilities in various industrial applications. It features a rugged stainless steel design, ensuring durability under harsh conditions.

    This input module is specifically designed to handle significant force inputs, offering a capacity of up to 16 KN (3600 lbs). Its ±0.02% FSO accuracy ensures reliable measurements, critical for maintaining quality control in production processes.

    Designed with IP67 protection, this load cell input module is protected against dust and water ingress, making it suitable for outdoor and industrial environments where exposure to environmental factors is common.

    With a wide operating temperature range from -20°C to +80°C, the ABB Load Cell Input Module can function effectively in varying climate conditions, providing consistent performance across different geographical locations and operational settings.

    The unit comes with easy installation options, including pre-installed connectors, facilitating quick setup and integration into existing systems. This feature minimizes downtime and ensures minimal disruption during installation.
