Relay Type:Motor Management Relay

Model:SR469-P5-H1-A20-E

Manufacturer:GE-FANUC

Control Power Supply Voltage:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

Phase Current Capacity:5 A

CT Secondary Rating:5A

Display:Enhanced display, larger LCD

Humidity Resistance:Up to 90%, non-condensing

RS-232 Interface Baud Rate:Programmable up to 19,200 baud

Analog Output:Four (4) 4 to 20 mA analog outputs

Temperature Measurement Inputs:3 wire: 100 Ω Platinum, 100 Ω Nickel, 120 Ω Nickel, 10 Ω Copper

    The GE SR469 469-P5-H1-A20-E Generator Management Relay is a comprehensive solution for monitoring and managing the health and efficiency of industrial motors. It seamlessly integrates into various applications, ensuring the protection of your critical machinery.

    With its advanced multiple RTD inputs, the relay accurately determines both the actual temperature and the hottest point within the motor system, allowing for precise monitoring and proactive maintenance.

    Featuring a durable and user-friendly design, the front panel of this relay includes an RS-232 program port interface with a programmable baud rate, offering flexibility and convenience for integration and setup.

    The draw-out handle is designed with a locking mechanism, ensuring the security of the relay module during operation and maintenance, thus preventing unauthorized removal and enhancing operational safety.

    Engineered to withstand harsh industrial environments, the GE SR469 469-P5-H1-A20-E Generator Management Relay boasts an enclosure rating suitable for various conditions, coupled with high insulation voltage ratings and pollution degree resistance, making it a reliable choice for a wide range of industrial applications.
