Board Type:Serial Measurement

Model Number:3HAB2213-1/5

Compatibility:Universal for various industrial protocols

Data Acquisition Rate:Up to 1 Mbaud

Power Consumption:12V DC, 50mA max.

Operating Temperature Range:-20°C to +70°C

Environmental Resistance:IP20

Connection Type:RS-485 / RS-422

Dimensions:85mm x 50mm x 17mm

Weight:30g

    The ABB 3HAB2213-1/5 Serial Measurement Board is engineered for seamless integration into a wide range of industrial automation setups, ensuring reliable and efficient data transmission. Its robust design withstands challenging industrial environments, making it ideal for use in manufacturing, process control, and other demanding applications.

    This serial measurement board features a high-resolution sensor interface, enabling precise measurement and data conversion from various sensors and devices. Its versatile RS-485 interface supports easy connection to a variety of automation systems, facilitating seamless communication between different components.

    Engineered for durability, the board operates within a wide temperature range (-20°C to +60°C), ensuring stable performance under varying environmental conditions. Its compact size and lightweight construction make it easy to install and integrate into existing systems without compromising space or functionality.

    Featuring an adjustable power supply voltage (DC 9V to 36V), this board can be easily powered by various sources, providing flexibility in deployment scenarios. Additionally, its low current consumption (Max. 100mA) ensures efficient energy use, reducing operational costs and environmental impact.

    Certified to international standards (CE, UL, CSA), the ABB 3HAB2213-1/5 Serial Measurement Board complies with stringent safety regulations, guaranteeing reliability and user safety. Its compatibility with major automation protocols ensures seamless integration into existing control systems, streamlining setup and maintenance processes.
