Brand:ABB

Model:DSQC236A

Module Type:Communication Module

Operating Voltage:12 to 48 VDC

Data Transfer Rate:Up to 1 Mbps

Number of Analog Inputs:4

Number of Digital Inputs:16

Number of Digital Outputs:16

Bus Compatibility:EtherCAT, DeviceNet, CANopen, Profinet

Memory Size:2K bytes

Dimensions (W x H x D):54.5 x 105.5 x 96.5 mm

Weight:170 g

Operating Temperature:-25°C to +70°C

Humidity Range:5 to 95% non-condensing

    The ABB DSQC236A is an essential component for enhancing the efficiency and reliability of industrial automation systems. Designed with high performance and durability in mind, this modular input/output module supports up to 16 digital inputs and outputs, providing precise control over machinery and processes.

    Featuring DeviceNet communication protocol, the DSQC236A ensures seamless data exchange between the module and other devices within the network, facilitating real-time monitoring and control.

    With its robust design, the module is capable of operating under extreme temperatures ranging from -25°C to +70°C, ensuring stable performance in various industrial environments. The IP20 protection rating further enhances its reliability by safeguarding against dust and splashing water.

    For ease of installation and integration, the ABB DSQC236A is panel-mounted, allowing for compact and efficient use in space-constrained applications. The compact size (15 mm x 67 mm x 100 mm) and lightweight design (approx. 40 g) make it an ideal choice for a wide range of industries seeking to optimize their automation systems.

    This module is designed with user-friendliness in mind, featuring intuitive configuration options through ABB’s comprehensive software suite. It supports various programming languages, enabling quick setup and customization to meet specific application requirements.
