ABB

Key Specifications: Power Rating: 6.6 kW continuous output Input Voltage: 3-phase 200-480V AC (±10%) Output Current: 26 A peak (model-specific) Control Technology: Field-oriented vector control Feedback Interface: Supports absolute/incr. encoders (20-bit+ resolution) Communication Protocols: EtherCAT (IEEE 1588 time sync) PROFINET RT/IRT CANopen DS402 Technical Features: ✓ Advanced Control Algorithms: Adaptive vibration suppression Anti-resonance filtering Torque ripple compensation ✓ Safety Functions: STO (Safe Torque Off) SIL3/PLe SS1/SS2 Safe Stop SLS Safe Limited Speed

181

ABB

Key Features: Rated Voltage: 12 kV (or as specified; confirm based on regional standards). Breaking Capacity: High short-circuit interruption (e.g., 20–25 kA). Technology: Vacuum interrupter for arc-free switching and long service life. Operation: Spring-operated or motor-driven mechanism (dependent on model). Protection Functions: Overcurrent, earth fault, and customizable relay logic (if equipped with digital controls). Standards Compliance: IEC 62271, ANSI C37.04 (global certifications).

602

ABB

Core Components ACS800-01-0025-3 Drive Unit Power: 25kW (33HP) Current: 45A Voltage: 380-480V AC (±10%) Control: Direct Torque Control (DTC) Enclosure: IP21 (NEMA 1) E200 DC Reactor Inductance: 2.5mH Current: 50A Function: Reduces harmonics & improves power factor P901 Mounting Kit Cabinet Material: Powder-coated steel Cooling: Forced ventilation Protection: IP21 when installed P915 Operator Panel Display: Backlit LCD Keypad: IP54 protection Functions: Start/stop, parameter adjustment, diagnostics Key Features ✔ Complete Plug-and-Play Solution - Ready for cabinet installation ✔ Enhanced Power Quality - With integrated DC reactor ✔ User-Friendly Operation - Full-featured control panel ✔ Space-Efficient Design - Optimized cabinet layout Technical Specifications Dimensions (installed): 600 × 400 × 300mm (H×W×D) Weight: 35kg (complete system) Ambient Temperature: 0-40°C Certifications: CE, UL, cUL, RoHS

465

ABB

Core Specifications 1. Drive Unit (ACS800-04-0400-3) Power Rating: 400kW (536HP) Output Current: 578A Input Voltage: 380-480V AC (±10%), 3-phase Control Technology: Direct Torque Control (DTC) Efficiency: >97.5% Enclosure: IP00 (requires P901 cabinet) 2. P901 Cabinet Kit Material: Powder-coated steel Mounting: Floor-standing or wall-mounted Cooling: Forced ventilation (fans included) Protection Class: IP21 with cabinet Cable Entry: Bottom/top (configurable) Key Features ✔ Plug-and-Play Installation - Pre-configured mounting solution ✔ Optimized Airflow - Intelligent thermal management ✔ Service-Friendly - Front-access design ✔ Vibration-Resistant - Industrial-grade construction Certifications CE, UL, cUL EN 61800-3 (EMC) RoHS compliant

222

ABB

Technical Specifications 1. Drive Unit (ACS800-07-0770-3) Rated Power: 630kW (845HP) Output Current: 850A continuous Input Voltage: 380-480V AC, 3-phase (±10%) Control Method: Direct Torque Control (DTC) Efficiency: >98% (typical) Enclosure: IP21 (NEMA 1) Cooling: Forced air 2. Brake Chopper (D150) Braking Capacity: 150kW Peak Current: 300A (for 5 seconds) DC Link Voltage: 725V nominal Duty Cycle: 10% ED standard Key Features Seamless integration between drive and brake unit Automatic braking torque adjustment Regenerative energy dissipation during deceleration Built-in thermal protection LED status indicators for quick diagnostics Certifications & Compliance CE Marked UL Listed cUL Certified EN 61800-3 (EMC) RoHS Compliant

428

ABB

Key Specifications Electrical Parameters: Power Rating: 130kW (175HP) Current Output: 250A Input Voltage: 380-480V AC (±10%) Frequency: 50/60Hz Control Features: Direct Torque Control (DTC) Built-in PID controller 0.1% speed regulation accuracy Physical Specifications: Dimensions: 400 × 300 × 200mm (W×H×D) Weight: 25kg Cooling: Forced air Protection Class: IP20 Certifications CE, UL, cUL EN 61800-3 (EMC) RoHS compliant

857

ABB

ABB ACS800-104-0460-5+E205+Q950+V991 Drive System Basic Parameters Drive Unit: ACS800-104-0460-5 Power: 460kW (616HP) Current: 510A Voltage: 525-690V AC Cooling: Liquid Options E205 Capacitor Bank 120,000μF, 900V DC Q950 Cooler 12kW cooling capacity V991 Protection 825V DC cutoff Features ✔ DTC control technology ✔ SIL3 safety compliance ✔ Liquid-cooled design

477

ABB

ABB ACS800-104-0610-5+E205+V991 Drive System Base Unit (ACS800-104-0610-5) Power: 610kW (818HP) Current: 590A Voltage: 525-690V AC Topology: IGBT PWM Cooling: Liquid (standard) Options E205 Capacitor Bank Capacity: 150,000μF Voltage: 900V DC V991 Protection Module OVP: 825V DC cutoff Response: <1ms Certifications CE, UL, cUL EN 61800-3 (EMC) SIL3 compliant

121

ABB

ABB ACS800-104-0610-5+Q967+V991 Industrial Drive Package Core Specifications Drive Model: ACS800-104-0610-5 Power: 610kW (818HP) Current: 590A Voltage: 525-690V AC (±10%) Topology: IGBT PWM Enclosure: IP00 (Open Type) Key Options Q967 Liquid Cooling Unit Cooling Capacity: 18kW Flow Rate: 15L/min Pressure: 2.5bar max V991 Overvoltage Protection Threshold: 825V DC Response Time: <1ms Certifications CE, cULus EN 61800-3 (EMC) SIL3 (Safety Integrity Level)

113

ABB

Key Parameters Base Drive Unit (ACS800-104-0580-7) Power: 580kW (777HP) Current: 835A Voltage: 525-690V AC (±10%) Enclosure: IP00 (Open chassis) Cooling: Liquid cooling Included Options E205 Electrolytic Capacitor Bank Capacitance: 120,000μF Voltage: 900V DC Q967 Liquid Cooling Unit Cooling Capacity: 15kW Flow Rate: 12L/min Pressure Drop: 1.5bar V991 Voltage Protection Module OVP Threshold: 825V DC Response Time: <1ms Certifications CE, UL, cUL EN 61800-3 (EMC) SIL 3 (Safety)

899

ABB

Core Specifications Drive Model: ACS800-04-0400-3 Power: 400kW (536HP) Current: 578A Voltage: 380-480V AC (±10%) Enclosure: IP21 (NEMA 1) Options Included D150 Brake Chopper Unit Braking Power: 150kW Voltage: 725V DC Peak Current: 300A (5s) P901 Cabinet Mounting Kit Material: Powder-coated steel Cooling: Forced ventilation Compatibility: ACS800-04 series Certifications CE, UL, cUL EN 61800-3 (EMC) RoHS compliant

98

ABB

Key Specifications Electrical Parameters: Voltage Rating: 230V AC (50/60Hz) Max Continuous Voltage (Uc): 275V AC Nominal Discharge Current (In): 10kA (8/20μs) Impulse Current (Iimp): 25kA (10/350μs) Voltage Protection Level (Up): ≤1.5kV Protection Features: Combined Protection: Meets Type 1+2 requirements (IEC 61643-11) Thermal Disconnector: Automatic fail-safe mechanism Visual Status Indicator: Green/Red window Remote Signaling: Optional contact available Mechanical Specifications: Mounting: DIN rail (35mm) Connection: 10mm² max wire size Housing Material: Flame-retardant thermoplastic (UL94 V-0) Dimensions: 90 x 70 x 65mm (WxHxD) Weight: 0.35kg Certifications & Standards IEC 61643-11 (Type 1+2) EN 61643-11 compliant CE Marked UL 1449 4th Edition Listed RoHS & REACH compliant

856
