ABB

Key Specifications: Power Rating: 0.25 kW (0.33 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 1.0 A Overload Capacity: 150% for 3 seconds Control Technology: Flux-optimized DTC (Direct Torque Control) Switching Frequency: Up to 16 kHz (adjustable) Main Features: 1. Advanced Motor Control: Sensorless vector control with 0.5% speed accuracy Automatic motor adaptation (AMA) Torque control mode (±3% accuracy) Flying start and DC braking 2. Application-Specific Functions: 5 pre-programmed application macros Customizable application programs Built-in PID controller with sleep/wake function Pump and fan control curves 3. Enhanced Connectivity: Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP-V1 DeviceNet CANopen USB service port for quick parameter transfer Physical Characteristics: Enclosure Rating: IP20 (open type) Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.65 kg Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

130

ABB

Key Specifications: Power Rating: 0.37 kW (0.5 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 1.6 A Overload Capacity: 150% for 3 seconds Control Method: Open-loop vector control Switching Frequency: 2-16 kHz (adjustable) Main Features: Compact Design: Ultra-compact IP20 enclosure Built-in EMC filter (Class A) Optional IP66/NEMA 4X protection kit available Advanced Motor Control: Sensorless vector control technology Automatic motor adaptation (AMA) Flying start function Torque boost capability Application Flexibility: 3 pre-programmed application macros Customizable application programs Built-in PID controller Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 4 digital inputs 1 relay output 1 analog output (0/4-20mA) Communication Options: Built-in Modbus RTU (RS485) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics: Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.7 kg Cooling: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

746

ABB

Key Specifications: Power Rating: 0.75 kW (1 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 2.4 A Overload Capacity: 150% for 3 seconds Control Method: Open-loop vector control Switching Frequency: Up to 16 kHz Main Features: Compact Design: Space-saving IP20 enclosure Built-in EMC filter (Class A) Optional IP66/NEMA 4X kit available Advanced Control: Sensorless vector control Automatic motor adaptation (AMA) Flying start function Torque boost Application Macros: Factory preset configurations Customizable application programs Built-in PID controller Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 4 digital inputs 1 relay output 1 analog output Communication Options: Built-in Modbus RTU (RS485) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics: Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.8 kg Cooling: Convection cooling Ambient Temperature: -10°C to +50°C (14°F to 122°F)

203

ABB

Key Specifications Power Rating: 5.5 kW (7.5 HP) Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz Output Current: 12 A Overload Capacity: 110% for 60s, 150% for 3s Control Method: Scalar (V/f) & Sensorless Vector Control (optional) Switching Frequency: 1–16 kHz (adjustable) Efficiency: >97% Main Features ✔ Energy-Saving Operation Automatic Energy Optimizer reduces motor losses Sleep/Wake function for pump & fan applications ✔ Built-in Application Macros Pre-configured settings for pumps, fans, and constant torque applications PID controller for pressure/flow control ✔ Protection & Safety Motor thermal protection (PTC input) Short-circuit, overvoltage, and ground fault protection IP21 enclosure (basic dust protection) ✔ Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 3 digital inputs, 1 relay output Optional fieldbus adapters (Profibus, BACnet, etc.) ✔ User-Friendly Interface Integrated control panel with LED display Quick start-up wizard for easy commissioning Physical & Environmental Specifications Enclosure Rating: IP21 (open chassis) Cooling Method: Convection cooling (fanless design) Ambient Temperature: -10°C to +50°C (14°F to 122°F) Dimensions (W×H×D): 150 × 200 × 165 mm Weight: 2.1 kg

247

ABB

Key Specifications Power Rating: 500 kW (670 HP) Input Voltage: 3-phase 380–500V AC (±10%), 50/60 Hz Output Current: 850 A Overload Capacity: 110% continuous, 150% for 60s Control Method: Sensorless Vector Control (DTC option available) Efficiency: >98% Switching Frequency: Adjustable (2–8 kHz) Main Features ✔ Advanced Motor Control Sensorless vector control for precise speed regulation Automatic motor adaptation (AMA) for optimal performance Flying start and torque boost functions ✔ Built-in Application Macros Pre-programmed settings for pumps, fans, conveyors, and compressors Customizable logic with PID controller (for pressure/flow control) ✔ Protection & Safety Motor thermal protection (PTC/KTY support) Short-circuit, overvoltage, and ground fault protection Safe Torque Off (STO) for emergency stop compliance ✔ Connectivity & Communication Standard RS485 (Modbus RTU) Optional fieldbus modules (Profibus, Ethernet/IP, Modbus TCP) ABB Drive Composer software for easy configuration ✔ User-Friendly Interface Integrated keypad with LCD display Quick setup with assisted startup wizard Parameter backup via USB Physical & Environmental Specifications Enclosure Rating: IP21 (open chassis) Cooling Method: Forced air cooling (fans included) Ambient Temperature: 0–40°C (32–104°F) without derating Dimensions (W×H×D): 800 × 1800 × 400 mm Weight: Approx. 200 kg

988

ABB

Technical Specifications: Main Drive Unit (ACS880-04-725A-3): Power Rating: 725 kW (971 HP) Input Voltage: 3-phase 380-500V AC (-15%/+10%) Output Current: 1040 A Overload Capacity: 110% continuous, 150% for 60s Control Technology: DTC (Direct Torque Control) Efficiency: >98.5% Switching Frequency: 1-4 kHz (adjustable) D150 Control Panel Features: 7" color touchscreen display Multilingual interface (20+ languages) Real-time process monitoring Built-in trend recorder Password protection levels USB port for parameter transfer Key System Features: Advanced Control Capabilities: Sensorless vector control (SLVC) Encoderless speed control (±0.1% accuracy) Torque control mode (±2% accuracy) Adaptive programming capability Application-Specific Functions: Multiple application macros Customizable logic functions Built-in safety functions (STO, SS1, SLS) Advanced PID controller Protection & Monitoring: Motor thermal protection (PTC/KTY84) Ground fault detection Input phase monitoring DC link monitoring IGBT temperature monitoring Communication Interfaces: Standard: Modbus RTU (RS485) Ethernet Optional: PROFIBUS DP PROFINET EtherNet/IP CANopen Physical Specifications: Drive Dimensions: 900 × 2200 × 600 mm (W×H×D) Control Panel Dimensions: 210 × 170 × 60 mm Weight: 320 kg (drive only) Cooling: Liquid cooling system Ambient Temperature: 0-40°C (32-104°F) Certifications & Compliance: CE UL cULus DNV GL IEC 61800-3 ISO 13849-1 (PL e)

353

ABB

Technical Specifications: Power Rating: 2.2 kW (3 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 5.2 A Overload Capacity: 150% for 60 seconds Control Technology: DTC (Direct Torque Control) Encoder Interface: N671 module for incremental encoders Key Features: Precision Control: Closed-loop vector control with encoder feedback ±0.01% speed accuracy (with encoder) 0.1 Hz speed control range Encoder Module (N671): Supports 5V/24V incremental encoders Resolution up to 4096 ppr Differential (RS422) and single-ended inputs LED status indicators

702

ABB

Technical Specifications: Power Rating: 37 kW (50 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 65 A Overload Capacity: 150% for 60 seconds Control Technology: DTC (Direct Torque Control) Frequency Range: 0-500 Hz Efficiency: >98% Key Features: Advanced Control Capabilities: Sensorless vector control Automatic motor adaptation Torque control mode Flying start function Application-Specific Functions: Built-in PID controller Pump and fan control curves Multiple preset macros Custom application programming Protection Systems: Motor thermal protection Short circuit protection Ground fault detection Input phase monitoring Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 2 relay outputs 1 analog output (0/4-20mA) Communication: RS485 (Modbus RTU standard) Optional fieldbus adapters available Physical Characteristics: Enclosure: IP21 (open chassis) Dimensions: 350 × 482 × 227 mm (W × H × D) Weight: 18.5 kg Cooling: Forced air cooling Ambient Temperature: 0-40°C (32-104°F) without derating

755

ABB

Technical Specifications: Power Rating: 7.5 kW (10 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 18 A Overload Capacity: 150% for 60 seconds Control Method: Sensorless vector control (DTC) Frequency Range: 0-500 Hz Efficiency: >97.5% Key Features: Advanced Motor Control: Automatic motor adaptation (AMA) Torque boost function Flying start capability Application Macros: Factory preset configurations (pump, fan, conveyor) Customizable application programs Built-in PID controller Protection Features: Motor thermal protection (PTC input) Short circuit protection Ground fault detection Overvoltage/undervoltage protection Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 1 analog output (0/4-20mA) Communication: RS485 (Modbus RTU standard) Optional fieldbus adapters available Physical Characteristics: Enclosure: IP20 (open chassis) Dimensions: 198 × 245 × 195 mm (W × H × D) Weight: 4.2 kg Cooling: Convection cooling Ambient Temperature: 0-40°C (32-104°F) without derating

137

ABB

Core Parameters: Model: ACS800-104-0510-3+E205+V991 Power: 15kW/20HP Input: 3PH 380-480VAC, 50/60Hz Output: 31A, 0-480V Control: DTC technology Overload: 150% for 60s Options Included: E205: +4AI(2x0-10V/2x4-20mA), +4DI, +2RO, +1AO(0-20mA) V991: Parameter backup module Protection: IP21, built-in EMC filter Motor thermal/ground fault/short circuit protection Comms: Modbus RTU standard Fieldbus options available Dimensions: 245×482×227mm (W×H×D) Weight: 12.5kg Certifications: CE/UL/cULus/RoHS

521

ABB

Technical Specifications: Power Rating: 1.1 kW (1.5 HP) Input Voltage: 3-phase: 380-480V AC ±10% Frequency: 48-63 Hz Output Current: 3.0 A Overload Capacity: 150% for 60 seconds Brake Chopper: Integrated (P901 option) Control Technology: DTC (Direct Torque Control) Key Features: Advanced Motor Control: Sensorless vector control Automatic motor adaptation (AMA) Flying start function Application Macros: Factory preset configurations Customizable application programs PID controller with sleep/wake function Protection Features: Motor thermal protection Short circuit protection Ground fault detection Overvoltage/undervoltage protection Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 1 analog output Communication: Modbus RTU (standard) Optional fieldbus adapters available Physical Characteristics: Enclosure: IP21 (open chassis) Cooling Method: Convection cooling Ambient Temperature: 0-40°C without derating Mounting Options: Wall or DIN rail mounting

632

ABB

Technical Specifications: Power Rating: 0.75 kW (1 HP) Input Voltage: 3-phase: 200-240V AC (-15%/+10%) 1-phase: 200-240V AC (-15%/+10%) Output Current: 3.6 A Overload Capacity: 150% for 60 seconds Brake Chopper: Integrated (P901 option) Switching Frequency: 1-12 kHz (adjustable) Key Features: ✔ Advanced Control Modes: DTC (Direct Torque Control) technology Scalar control (V/f) mode Customizable torque curves ✔ Application-Specific Features: Pump and fan control macros PID controller with sleep/wake function Flying start capability ✔ Protection Functions: Motor thermal protection Short circuit protection Ground fault detection Overvoltage/undervoltage protection Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 1 analog output Communication Options: Modbus RTU (standard) Optional fieldbus adapters (Profibus, DeviceNet) Physical Characteristics: Enclosure: IP21 (open chassis) Cooling: Convection cooling Ambient Temperature: 0-40°C (32-104°F) without derating Mounting: Wall or DIN rail mounting
