ABB

Key Specifications: Power Rating: 3.0 kW (4 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 7.2 A Overload Capacity: 150% for 3 seconds Control Method: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97.5% Main Features: Advanced Control Technology: ✓ ABB's Direct Torque Control (DTC) ✓ Automatic Motor Adaptation (AMA) ✓ Torque boost function ✓ Flying start capability Application Flexibility: ✓ 5 pre-programmed application macros ✓ Built-in PID controller ✓ Customizable application programs ✓ Pump and fan control curves Protection & Safety: ◆ Motor thermal protection (PTC/KTY) ◆ Short circuit and ground fault protection ◆ Safe Torque Off (STO) option ◆ Overvoltage/undervoltage protection Connectivity Options: ◉ Standard RS485 (Modbus RTU) ◉ Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen ◉ USB service port for configuration Physical Specifications: Dimensions: 150 × 200 × 165 mm (W×H×D) Weight: 1.8 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Operating Temperature: -10°C to +50°C (14°F to 122°F)

51

ABB

Key Specifications Power Rating: 1.1 kW (1.5 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 3.0 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function (±3% accuracy) Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety Motor thermal protection (PTC/KTY supported) Short circuit and ground fault protection Safe Torque Off (STO) option (SIL3/PL e) ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.7 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

662

ABB

Key Specifications Power Rating: 0.55 kW (0.75 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 1.7 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety Motor thermal protection (PTC input) Short circuit and ground fault protection Safe Torque Off (STO) option ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.65 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

544

ABB

Key Specifications Power Rating: 0.75 kW (1 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 2.1 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic motor adaptation (AMA) Torque boost function (±3% accuracy) Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety Motor thermal protection (PTC/KTY supported) Short circuit and ground fault protection Safe Torque Off (STO) option (SIL3/PL e) ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.7 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

580

ABB

Key Specifications Power Rating: 4 kW (5 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 9.5A Overload Capacity: 150% for 3 seconds Control Method: Sensorless vector control Switching Frequency: 2-16kHz (adjustable) Efficiency: >97% Main Features Advanced Motor Control Precise speed regulation (±0.5% accuracy) Automatic Motor Adaptation (AMA) Torque boost function Flying start capability Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable logic functions Protection & Safety Motor thermal protection (PTC/KTY) Short circuit and ground fault protection Safe Torque Off (STO) option Connectivity Options RS485 (Modbus RTU) standard Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 150 × 200 × 165mm (W×H×D) Weight: 2.1kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature: -10°C to +50°C (14°F to 122°F)

699

ABB

Key Specifications Power Rating: 55 kW (75 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 110 A Overload Capacity: 150% for 3 seconds Control Method: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Main Features 1. Advanced Motor Control Direct Torque Control (DTC) technology Automatic motor adaptation (AMA) Torque control mode (±3% accuracy) Flying start function 2. Application-Specific Functions Multiple application macros Customizable logic functions Built-in PID controller Pump and fan control curves 3. Enhanced Connectivity Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen USB service port Physical Characteristics Enclosure Rating: IP20 (open type) Dimensions: 350 × 482 × 227 mm (W×H×D) Weight: 18 kg Cooling Method: Forced air cooling Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

108

ABB

Key Specifications ✔ Power Rating: 0.75 kW (1 HP) ✔ Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz ✔ Output Current: 2.1 A ✔ Overload Capacity: 150% for 3 seconds ✔ Control Method: Sensorless Vector Control (DTC option available) ✔ Switching Frequency: 2–16 kHz (adjustable) ✔ Efficiency: >97% Main Features 1. Advanced Motor Control Sensorless vector control for precise speed regulation (±0.5% accuracy) Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback Torque boost & flying start – ensures smooth operation under load 2. Application Flexibility Pre-programmed macros (pump, fan, conveyor) for quick setup Built-in PID controller for process control (pressure, flow, temperature) Customizable logic via free function blocks 3. Protection & Safety Motor thermal protection (PTC/KTY input) Short-circuit, overvoltage, and ground fault protection Safe Torque Off (STO) – SIL3/PL e safety compliance 4. Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 4 digital inputs, 1 relay output Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen) 5. Compact & Robust Design IP20 enclosure (dust protected) Optional IP66/NEMA 4X kit for harsh environments Built-in EMC filter (Class A compliance) Physical & Environmental Specs Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.7 kg Cooling: Convection cooling (fanless) Ambient Temp: -10°C to +50°C (14°F to 122°F)

507

ABB

Key Specifications: Power Rating: 1.5 kW (2 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 3.6 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Main Features: ✔ Advanced Motor Control: Direct Torque Control (DTC) technology Automatic motor adaptation (AMA) Torque boost function Flying start capability ✔ Application Flexibility: 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety: Motor thermal protection (PTC/KTY) Short circuit and ground fault protection Safe Torque Off (STO) option ✔ Connectivity Options: RS485 (Modbus RTU) standard Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics: Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.8 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature: -10°C to +50°C (14°F to 122°F)

332

ABB

Key Specifications Power Rating: 1.5 kW (2 HP) Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz Output Current: 3.6 A Overload Capacity: 150% for 3 seconds Control Method: Scalar (V/f) control Switching Frequency: 2–16 kHz (adjustable) Efficiency: >96% Main Features ✔ Reliable Motor Control V/f control with torque boost Automatic Energy Optimizer for efficiency DC braking capability ✔ Application Flexibility 3 preset speed settings Basic PID controller Customizable acceleration/deceleration ramps ✔ Protection Features Motor thermal protection Short-circuit and overcurrent protection Ground fault detection ✔ Standard Interfaces 2 analog inputs (0–10V/4–20mA) 3 digital inputs 1 relay output RS485 (Modbus RTU) communication ✔ Compact Design IP20 enclosure Lightweight (1.1 kg) Convection cooling (fanless) Physical & Environmental Specs Dimensions: 150 × 200 × 165 mm (W×H×D) Weight: 1.1 kg Cooling: Natural convection Ambient Temp: 0°C to +40°C (32°F to 104°F)

585

ABB

Key Specifications Power Rating: 1.5 kW (2 HP) Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz Output Current: 3.6 A Overload Capacity: 150% for 3 seconds Control Method: Sensorless Vector Control (DTC option available) Switching Frequency: 2–16 kHz (adjustable) Efficiency: >97% Main Features ✔ Advanced Motor Control Sensorless vector control for precise speed regulation (±0.5% accuracy) Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback Torque boost & flying start – ensures smooth operation under load ✔ Application Flexibility Pre-programmed macros (pump, fan, conveyor) for quick setup Built-in PID controller for process control (pressure, flow, temperature) Customizable logic via free function blocks ✔ Protection & Safety Motor thermal protection (PTC/KTY input) Short-circuit, overvoltage, and ground fault protection Safe Torque Off (STO) – SIL3/PL e safety compliance ✔ Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 4 digital inputs, 1 relay output Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen) ✔ Compact & Robust Design IP20 enclosure (dust protected) Optional IP66/NEMA 4X kit for harsh environments Built-in EMC filter (Class A compliance) Physical & Environmental Specs Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.8 kg Cooling: Convection cooling (fanless) Ambient Temp: -10°C to +50°C (14°F to 122°F)

780

ABB

Key Specifications Power Rating: 0.1 kW (0.13 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 0.6A Overload Capacity: 150% for 3 seconds Control Method: Sensorless vector control Switching Frequency: Up to 16kHz (adjustable) Main Features 1. Compact & Efficient Design Industry's smallest footprint in its class (70×170×145mm) Lightweight (0.6kg) IP20 enclosure Optional IP66/NEMA 4X kit available Built-in EMC filter (Class A) 2. Advanced Motor Control Sensorless vector control technology Automatic motor adaptation (AMA) Flying start capability Torque boost function 3. Application Flexibility 3 pre-programmed application macros Customizable application programs Built-in PID controller Standard Interfaces Control Terminals: 2 analog inputs (0-10V/4-20mA) 4 digital inputs 1 relay output Communication: RS485 (Modbus RTU standard) Optional fieldbus adapters available Physical Characteristics Dimensions: 70×170×145mm (W×H×D) Weight: 0.6kg Cooling: Natural convection Ambient Temperature: -10°C to +50°C

782

ABB

Key Specifications Power Rating: 0.1 kW (0.13 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 0.6 A Overload Capacity: 150% for 3 seconds Control Method: Scalar (V/f) control Switching Frequency: 2-16 kHz (adjustable) Main Features 1. Compact Design Ultra-small footprint (70 × 170 × 145 mm) Lightweight construction (0.6 kg) IP20 enclosure (open chassis) Optional IP66 protection kit available 2. Basic Control Functions V/f control with torque boost 3 preset speed settings DC injection braking Automatic restart after fault 3. Standard Interfaces 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output RS485 (Modbus RTU) communication Application Highlights Small fans and blowers Laboratory equipment Conveyor systems Basic pump control Light material handling Certifications & Compliance CE Marked UL Recognized RoHS Compliant EN 61800-3 EMC Standards

590
