Key Specifications Parameter Value Power Rating 0.75 kW (1 HP) Input Voltage 3-phase 380-480V AC (±10%) Output Current 2.4 A Overload 110% continuous, 150% for 3s Control Method Scalar (V/f) Switching Freq. 1-16 kHz (adjustable) Efficiency >96% Main Features ✔ HVAC-Optimized Control Automatic Energy Optimizer PID controller with sleep/wake Pump/fan preset curves ✔ Basic Connectivity RS485 (Modbus RTU) 2 analog inputs (0-10V/4-20mA) 3 digital inputs ✔ Protection Motor thermal protection Short-circuit protection Ground fault detection Physical Specs Dimensions: 150×200×165mm Weight: 1.8 kg Cooling: Natural convection IP Rating: IP20

926

ABB

Key Parameters Core Drive Power: 7.5kW (10HP) Input: 3-phase 380-480V AC (±10%) Output: 18A Control: DTC (Direct Torque Control) Overload: 150% for 60s Modules B056 - Basic Control Panel LCD display Keypad navigation E202 - I/O Extension +2AI (0-10V/4-20mA) +2DI +1RO P901 - Brake Chopper Braking power: 7.5kW cont. Requires external resistor Performance Speed accuracy: ±0.1% Switching freq.: 1-12kHz Physical Dimensions: 245×482×227mm (W×H×D) Weight: 12kg Cooling: Forced air IP Rating: IP21 Certifications CE, UL, cUL

213

ABB

Key Specifications Power & Performance Rated Power: 11 kW (15 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 25 A Overload Capacity: 110% continuous 150% for 3 seconds Control Method: Scalar (V/f) & Sensorless Vector Control Efficiency: >97% Switching Frequency: 2-16 kHz (adjustable) Main Features 1. Motor Control V/f control with torque boost Automatic Energy Optimizer DC braking capability 2. Application Features 3 preset speed settings Basic PID controller Customizable acceleration/deceleration 3. Protection & Safety Motor thermal protection Short-circuit protection Ground fault detection 4. Connectivity Standard: RS485 (Modbus RTU) 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 5. Compact Design Space-saving IP20 enclosure Lightweight (7.5 kg) Fanless cooling Physical Specifications Dimensions: 150 × 245 × 195 mm (W×H×D) Weight: 7.5 kg Cooling: Convection Ambient Temperature: 0-40°C (32-104°F)

102

ABB

Key Specifications Power & Performance Rated Power: 200 kW (268 HP) Input Voltage: 3-phase 380-500V AC (±10%), 50/60 Hz Output Current: 430 A Overload Capacity: 110% continuous 150% for 60 seconds Control Method: Direct Torque Control (DTC) Efficiency: >98.5% Switching Frequency: 1-4 kHz (adjustable) Main Features 1. Advanced Motor Control DTC technology for precise speed (±0.1%) and torque (±1%) control Automatic motor adaptation Flying start and torque boost functions 2. Robust Design Heavy-duty power components for 24/7 operation Coated PCBs for harsh environments Modular design for easy maintenance 3. Application Flexibility 10 pre-programmed macros Customizable application programs Built-in PID controller 4. Protection & Safety Motor thermal protection (PTC/KTY) Short-circuit protection (IGBT monitoring) Ground fault detection Safe Torque Off (STO) 5. Connectivity Standard: RS485 (Modbus RTU) Ethernet Optional fieldbus: PROFIBUS DP PROFINET EtherNet/IP Physical Specifications Dimensions: 800 × 2200 × 450 mm (W×H×D) Weight: 185 kg Enclosure Rating: IP21 (IP54 kit available) Cooling: Liquid cooling (standard) Ambient Temperature: 0-40°C (32-104°F)

366

ABB

Key Specifications Power Rating: 55 kW (75 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 110 A Overload Capacity: 110% continuous, 150% for 60s Control Method: Sensorless vector control Efficiency: >98% (IE4 equivalent) THDi: <5% (with optional filter) Technical Highlights ✔ HVAC-Specific Intelligence Adaptive pump/fan control algorithms Automatic energy optimization (up to 25% savings) Built-in multi-pump controller Anti-condensation function ✔ Smart Connectivity Embedded BACnet MS/TP and Modbus RTU Cloud-ready with ABB Ability™ Optional wireless module (Wi-Fi/4G) Predictive maintenance capabilities ✔ Advanced Protection Motor thermal modeling (PTC/Pt100) Phase loss protection Surge protection (6kV/3kA) Safe Torque Off (STO) Physical Specifications Dimensions: 482 × 800 × 350 mm (H×W×D) Weight: 42 kg Enclosure: IP21 (IP55 kit available) Cooling: Forced air with ECO mode Ambient Range: -15°C to +50°C (5°F to 122°F) Certifications UL 61800-5-1 CE cULus EN 61800-3 Cat C2 ISO 13849-1 PL c

928

ABB

Key Specifications Power & Performance Rated Power: 30 kW (40 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 60 A Overload Capacity: 110% continuous 150% for 60 seconds Control Method: Sensorless Vector Control (DTC option) Efficiency: >98% (IE4 equivalent) Main Features 1. HVAC-Specific Control Adaptive programming for pumps and fans Automatic energy optimization Built-in PID controller with sleep/wake function Pump cleaning cycle program 2. Intelligent Connectivity Embedded Modbus RTU (RS485) BACnet MS/TP and Metasys N2 protocols Cloud connectivity via optional gateway ABB Ability™ enabled for remote monitoring 3. Protection & Safety Motor thermal protection (PTC/Pt100) Earth fault detection Surge protection (IEC 61000-4-5) Safe Torque Off (STO) 4. Physical Design Compact form factor (30% smaller than previous gen) IP21 enclosure (IP55 kit available) Corrosion-protected (C5-M coating) Plug-and-play installation Technical Highlights ✔ Energy Savings Features ECO mode saves up to 20% energy Automatic derating at partial loads Power factor >0.98 ✔ Application Flexibility 10 pre-programmed HVAC macros Customizable application programs Multi-pump control capability ✔ Monitoring & Diagnostics Built-in power quality monitoring 200-event fault log Predictive maintenance alerts Physical Specifications Dimensions: 350 × 482 × 227 mm (H×W×D) Weight: 15 kg Cooling: Convection (fanless) Ambient Temperature: -15°C to +50°C (5°F to 122°F) Relative Humidity: 5-95% non-condensing Certifications & Compliance CE UL 61800-5-1 cULus EN 61800-3 ISO 13849-1 (PL c)

55

ABB

Key Specifications Power & Performance Rated Power: 90 kW (125 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 180 A Overload Capacity: 150% for 60 seconds 110% continuous Control Method: Direct Torque Control (DTC) Braking Capacity (P901): Continuous: 90 kW Peak (60s): 135 kW Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features 1. Advanced Motor Control DTC technology for precise speed (±0.1%) and torque (±1%) control Automatic motor adaptation for optimal performance Flying start and torque boost functions 2. Brake Chopper (P901) Handles regenerative energy during deceleration Requires external brake resistor (sold separately) LED status indicator for fault monitoring 3. Application Flexibility Pre-programmed macros for: Pumps & fans Conveyors Cranes/hoists Built-in PID controller Customizable application programming 4. Protection & Safety Motor thermal protection (PTC/KTY support) Short-circuit and ground fault protection DC bus overvoltage/undervoltage protection Safe Torque Off (STO) compliant 5. Connectivity Standard: RS485 (Modbus RTU) Analog I/O (2xAI, 1xAO) Digital I/O (3xDI, 1xDO) Optional fieldbus: PROFIBUS DP DeviceNet CANopen Physical Specifications Dimensions: 482 × 800 × 350 mm (H×W×D) Weight: 65 kg Enclosure Rating: IP21 Cooling: Forced air (filtered) Ambient Temperature: 0-40°C (32-104°F)

588

ABB

Key Specifications Power Rating: 2.5 kW (3 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 6.5 A Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Encoder Interface: N671 module included Main Features ✔ Precision Motion Control Closed-loop speed control (±0.005% accuracy) Torque control (±0.5% accuracy) Automatic motor adaptation Position control capability ✔ N671 Encoder Module Supports incremental encoders (5V/24V) Resolution up to 4096 ppr Differential (RS422) and single-ended inputs LED status indicators ✔ Application Flexibility Multiple pre-programmed motion profiles Electronic gearing function Built-in PID controller Customizable application programming ✔ Protection & Safety Motor thermal protection Encoder loss detection Safe Torque Off (STO) Overvoltage/undervoltage protection Physical Characteristics Drive Dimensions: 245 × 482 × 227 mm (W×H×D) Weight: 8.5 kg (complete system) Enclosure Rating: IP21 Cooling Method: Convection cooling Ambient Temperature: 0-40°C (32-104°F)

30

ABB

Key Parameters Core Specifications Power: 40kW (55HP) Input: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 80A Overload: 150% for 60s Control: DTC (Direct Torque Control) Efficiency: >98% Modules P901 Brake Chopper Braking power: 40kW cont. / 60kW peak (60s) Requires external resistor N661 Encoder Interface Supports incremental encoders Resolution: Up to 4096 ppr Protocols: RS422/TTL Performance Speed accuracy: ±0.01% (with encoder) Torque accuracy: ±1% Switching freq.: 1-12kHz (adjustable) Physical Dimensions: 482×245×227mm (H×W×D) Weight: 18kg Cooling: Forced air Ambient Temp: 0-40°C Certifications CE, UL, cUL SIL3/PL e

316

ABB

Key Parameters Core Drive Power: 30kW (40HP) Input: 3-phase 380-500V AC (±10%) Output: 60A Control: DTC (Direct Torque Control) Overload: 150% for 60s Modules E200 I/O Extension 4AI (0-10V/4-20mA) 6DI + 2RO 1AO (0-20mA) K454 Fieldbus PROFIBUS DP-V1 12Mbps speed LB03 Cooling Liquid cooling system 8L/min flow requirement Physical Dimensions: 482×245×227mm (H×W×D) Weight: 38kg (complete) IP Rating: IP21 (standard) Certifications CE, UL, cUL SIL3/PL e

244

ABB

Key Specifications ✔ Power Rating: 20 kW (25 HP) ✔ Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz ✔ Output Current: 43 A ✔ Overload Capacity: 150% for 60 seconds 110% continuous ✔ Control Method: Direct Torque Control (DTC) ✔ Braking Capacity (P901): Continuous: 20 kW Peak (60s): 30 kW ✔ Switching Frequency: 1-12 kHz (adjustable) ✔ Efficiency: >98% Main Features 1. Advanced Motor Control DTC technology for precise speed (±0.1%) and torque (±2%) control Automatic motor adaptation for optimal performance Flying start and torque boost functions 2. Brake Chopper (P901) Handles regenerative energy during deceleration Requires external brake resistor (sold separately) LED status indicator for fault monitoring 3. Application Flexibility Pre-programmed macros for: Pumps & fans Conveyors Cranes/hoists Built-in PID controller Customizable application programming 4. Protection & Safety Motor thermal protection (PTC/KTY support) Short-circuit and ground fault protection DC bus overvoltage/undervoltage protection Safe Torque Off (STO) compliant 5. Connectivity Standard: RS485 (Modbus RTU) Analog I/O (2xAI, 1xAO) Digital I/O (3xDI, 1xDO) Optional fieldbus: PROFIBUS DP DeviceNet CANopen Physical Specifications Dimensions: 245 × 482 × 227 mm (W×H×D) Weight: 14 kg Enclosure Rating: IP21 Cooling: Forced air (filtered) Ambient Temperature: 0-40°C (32-104°F)

353

ABB

Key Specifications Power Rating: 11 kW (15 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 25 A Overload Capacity: 150% for 60 seconds Control Technology: DTC (Direct Torque Control) Brake Chopper: Integrated (P901 module) Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features ✔ Advanced Motor Control Sensorless speed control (±0.1% accuracy) Automatic motor adaptation Torque control mode (±2% accuracy) Flying start function ✔ Braking System (P901) Handles regenerative energy Requires external brake resistor LED status indicator 150% braking torque capacity ✔ Application Functions Multiple application macros Built-in PID controller Pump and fan control curves Customizable application programming ✔ Protection Features Motor thermal protection Short circuit protection Ground fault detection DC bus overvoltage protection Physical Characteristics Dimensions: 245 × 482 × 227 mm (W×H×D) Weight: 12 kg Enclosure Rating: IP21 Cooling Method: Forced air Ambient Temperature: 0-40°C (32-104°F)
