ABB

Key Features & Benefits: Industrial-Grade Performance Powerful processor for high-speed execution of control algorithms Deterministic real-time operation with <1ms cycle times Supports up to 300,000 I/O points (system-wide) Unmatched Reliability Redundant CPU and power supply configurations Hot-swappable modules for zero downtime maintenance Built-in diagnostics and predictive maintenance features Universal Connectivity Native support for 20+ communication protocols including: IEC 61850 (for substation automation) Profibus DP/PA, Modbus TCP/RTU OPC UA for secure data exchange Integrated web server for remote monitoring Engineering Flexibility Programmable with ABB’s Control Builder M software Supports all IEC 61131-3 languages plus CFC Seamless integration with ABB’s 800xA DCS Technical Specifications: Parameter Specification Processor PowerPC-based, 800MHz Memory 128MB RAM (expandable) I/O Capacity Up to 1024 local I/O points Communication Dual Ethernet ports (10/100Mbps) Operating Temp -40°C to +70°C Certifications UL, CE, IEC 61131, SIL2/3 compliant

167

ABB

Key Features Dual-Port Design 2 independent 10/100 Mbps Ethernet ports Auto-negotiation and auto-MDI/MDIX capability Switch functionality for daisy-chaining devices Industrial Reliability Operating temperature range: -40°C to +70°C High EMC immunity (EN 61000-6-2) DIN-rail mountable design Advanced Networking Supports MODBUS TCP, IEC 61850, and OPC UA protocols VLAN and QoS support for traffic prioritization Integrated firewall functionality Seamless Integration Hot-swappable module for AC 800M controllers Configuration via Control Builder M engineering tool LED status indicators for port activity and diagnostics Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (10BASE-T/100BASE-TX) Protocols Supported MODBUS TCP, IEC 61850, OPC UA Connectors 2x RJ45 (shielded) Power Consumption 1.5W typical Certifications UL, CE, IEC 61850-3, IEEE 1613

256

ABB

Key Features High-Performance Connectivity 10/100 Mbps Ethernet port with auto-negotiation RJ45 connector with industrial-grade shielding IEEE 802.3 compliant Industrial Durability Operating temperature: -40°C to +70°C High resistance to vibration and shock DIN-rail mountable design Protocol Support MODBUS TCP protocol support Compatible with ABB's industrial communication standards Transparent ready for system integration Easy Integration Plug-and-play installation for AC 800M controllers Configuration via Control Builder M LED status indicators for network monitoring Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (10BASE-T/100BASE-TX) Protocol Support MODBUS TCP Connector 1x RJ45 (shielded) Power Consumption 1.2W typical Certifications UL, CE, IEC 61131

525

ABB

Key Features & Benefits 1. High-Speed Industrial Communication Dual-Port PROFINET & Ethernet (10/100 Mbps, auto-negotiation) PROFINET RT (Real-Time) and IRT (Isochronous Real-Time) support for deterministic control Integrated switch functionality for daisy-chaining devices 2. Robust Industrial Design Wide operating temperature range (-20°C to +60°C) High EMC immunity (EN 61000-6-2) for harsh environments DIN-rail mounting for easy installation 3. Seamless Integration with ABB AC 500 PLCs Plug-and-play installation with AC500 controllers Configuration via Automation Builder (ABB’s engineering tool) LED diagnostics for quick troubleshooting 4. Cybersecurity & Network Management VLAN & QoS support for traffic prioritization Password protection & access control for secure operation SNMP monitoring for network diagnostics Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (10/100 Mbps) Protocols PROFINET RT/IRT, Modbus TCP, DHCP Ports 2x RJ45 (auto-MDI/MDIX) Power Consumption 1.8W typical Certifications CE, UL, IEC 61131, PROFINET Conformance Class B

632

ABB

Key Features Dual-Port Ethernet Connectivity 2x 10/100/1000 Mbps RJ45 ports with auto-negotiation Integrated switch functionality for daisy-chaining PROFINET RT/IRT, EtherNet/IP, and Modbus TCP support Industrial Reliability -40°C to +70°C operating temperature range High EMC immunity (EN 61000-6-2, IEC 61850-3) DIN-rail mountable with vibration-resistant design Advanced Networking Capabilities IEEE 1588 Precision Time Protocol (PTP) support VLAN and QoS for traffic prioritization Integrated firewall and security features Seamless Integration Plug-and-play with AC500 PLC systems Configuration via ABB Automation Builder Comprehensive LED diagnostics Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (1000BASE-T) Protocols PROFINET, EtherNet/IP, Modbus TCP Ports 2x RJ45 (shielded) Latency <1 μs (switch mode) Power Consumption 3.5W typical Certifications UL, CE, IEC 61850-3, IEEE 1613

247

ABB

Key Features & Benefits Robust Industrial Connectivity 10/100 Mbps Ethernet with auto-negotiation RJ45 connector with industrial-grade shielding IEEE 802.3 compliant for standard compatibility Industrial-Grade Reliability Operating temperature: -25°C to +60°C High resistance to vibration and electrical noise DIN-rail mountable design for easy installation Comprehensive Protocol Support Modbus TCP protocol for industrial communication Transparent ready for system integration DHCP support for automatic IP configuration Enhanced System Integration Plug-and-play installation with AC500 PLCs Configuration via ABB Automation Builder software LED status indicators for quick diagnostics Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (10BASE-T/100BASE-TX) Protocol Support Modbus TCP, DHCP Connector 1x RJ45 (shielded) Power Consumption 1.5W typical Certifications CE, UL, IEC 61131

743

ABB

Key Features & Benefits Advanced Ethernet Connectivity 10/100/1000 Mbps Gigabit Ethernet port Auto-negotiation and auto-MDI/MDIX capability PROFINET, EtherNet/IP, and Modbus TCP protocol support Industrial-Grade Durability Extended temperature range (-40°C to +70°C) High EMC immunity (EN 61000-6-2, IEC 61850-3) Vibration-resistant DIN-rail mounting design Enhanced Network Performance IEEE 1588 Precision Time Protocol (PTP) support VLAN and QoS for traffic prioritization Integrated firewall for network security Seamless System Integration Plug-and-play with AC500 PLC systems Configuration via ABB Automation Builder Comprehensive LED diagnostics indicators Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (1000BASE-T) Protocols PROFINET, EtherNet/IP, Modbus TCP Connector 1x RJ45 (shielded) Latency <1 μs Power Consumption 2.5W typical Certifications UL, CE, IEC 61850-3, IEEE 1613

743

ABB

Key Features & Benefits PROFIBUS DP Connectivity Supports PROFIBUS DP-V0 and DP-V1 protocols Transmission rates up to 12 Mbps 9.6 kbps to 12 Mbps auto-baud rate detection Industrial-Grade Reliability Operating temperature: -25°C to +60°C High immunity to electromagnetic interference DIN-rail mountable design Flexible Configuration Configurable as DP Master or Slave Supports up to 244 bytes of input/output data GSD file available for easy integration Diagnostic Capabilities Comprehensive LED status indicators Detailed diagnostic information available in controller Bus error detection and reporting Technical Specifications Parameter Specification Bus Protocol PROFIBUS DP (EN 50170) Transmission Rate 9.6 kbps - 12 Mbps Interface RS-485 (9-pin D-sub connector) Maximum Stations 125 (with repeater) Power Consumption 1.8W typical Certifications CE, UL, PROFIBUS International

843

ABB

Key Features & Benefits Fieldbus Power Conditioning Provides galvanic isolation between control system and field networks Integrated power conditioning with surge protection Supports FOUNDATION Fieldbus (FF) and PROFIBUS PA standards Robust Industrial Design -40°C to +70°C operating temperature range High immunity to EMI/RFI interference Compact DIN-rail mounting (1/8 DIN size) Advanced Protection Features Short-circuit and overload protection Polarity reversal protection Redundant power supply options available Diagnostic Capabilities LED status indicators for power and network health Remote monitoring capability via control system Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage FOUNDATION Fieldbus compliant Maximum Current 500mA (field side) Isolation Voltage 1500V DC Certifications ATEX, IECEx, UL, CE

855

ABB

Key Features & Benefits High-Efficiency Power Conversion 93% typical efficiency rating Active power factor correction (PFC >0.95) Wide input voltage range (85-264V AC) Industrial-Grade Reliability -25°C to +70°C operating temperature 150% power reserve for peak loads 50ms buffering time at full load Advanced Protection Features Short-circuit, overload, and overvoltage protection Automatic recovery function Reverse polarity protection Flexible Installation Compact DIN-rail design (105mm width) Plug-in screw terminal connections Status LED indicators Technical Specifications Parameter Specification Input Voltage 85-264V AC (47-63Hz) Output Voltage 24V DC (±0.5%) Output Current 6.3A (150% peak for 5s) Power Rating 150W Efficiency 93% typical Protection IP20 (front panel) Certifications UL, CE, cULus, EN 60950 Typical Applications ✔ PLC control cabinets ✔ Industrial machinery power systems ✔ Process automation panels ✔ Motor control centers ✔ Robotics and assembly systems

124

ABB

Key Features Enhanced Processing Performance 32-bit RISC processor @ 300 MHz 4MB program memory / 4MB data memory 0.1ms typical instruction execution time Versatile Communication Integrated RS232/RS485 ports Supports PROFIBUS DP, CANopen, and Ethernet (via expansion) SD card slot for program backup Industrial Durability Operating temperature: -25°C to +60°C Vibration resistant (5g @ 10-150Hz) Compact design (45mm width) Programming Flexibility Supports all IEC 61131-3 languages Compatible with ABB Automation Builder Online modification capability Technical Specifications Parameter Specification Processor 32-bit RISC @ 300MHz Memory 4MB Flash, 4MB RAM Digital I/O Up to 16,000 points (expandable) Analog I/O Up to 2,000 channels (expandable) Communication 1x RS232, 1x RS485 Power Consumption 8W typical Certifications CE, UL, cULus Typical Applications ✔ Machine automation ✔ Packaging systems ✔ Material handling ✔ Building management ✔ Water treatment plants

345

ABB

Key Features & Benefits Crisp Display & Touch Interface 5.7" STN LCD with LED backlight (320 x 240 pixels) Resistive touch screen for glove-friendly operation 65K color support for clear visualization Industrial Durability IP65-rated front panel protection -20°C to +60°C operating temperature range Vibration and shock resistant design Flexible Connectivity Integrated RS232/RS422/RS485 ports USB 2.0 host port for data transfer Supports ABB, Modbus, and other major protocols Easy Integration Pre-installed CODESYS runtime Compatible with ABB Automation Builder Plug-and-play with AC500 PLC systems Technical Specifications Parameter Specification Display Size 5.7" diagonal Resolution 320 x 240 pixels Touch Technology Resistive (single-touch) Processor 32-bit RISC @ 400MHz Memory 128MB Flash / 64MB RAM Communication 1x RS232/422/485, 1x USB 2.0 Power Supply 24V DC (18-32V range) Protection Rating IP65 (front) Typical Applications ✔ Machine operation panels ✔ Process control monitoring ✔ Packaging equipment interfaces ✔ Building automation systems ✔ Small-scale SCADA visualization

573
