Technical Specifications Parameter Specification Product Code PSE85-600-70 Series ABB PSE Electronic Motor Starters Rated Operational Current (Iₑ) 85 A (at 400V, 40°C ambient) Supply Voltage 3-phase, 380 - 690 V AC, 50/60 Hz Motor Power Range Approx. 45 - 55 kW (at 400V) Control Supply Voltage (Us) Selectable: 24 V AC/DC, 48-130 V AC, 110-130 V DC, or 200-240 V AC/DC Starting Method Voltage ramp with adjustable initial torque and ramp time. Starting Current Adjustable, typically up to 400% of motor Full Load Current (FLC). Stopping Method Coast stop (standard); programmable soft stop (optional). Motor Protection Class 10 electronic overload protection (I²t), phase loss/imbalance, jam/blocked rotor, underload, and PTC thermistor input for direct motor temperature monitoring. Enclosure IP00 (Open Type) for mounting inside a customer-supplied control cabinet. Ambient Temperature -25°C to +60°C (operating), with derating required above +40°C. Communication Via optional plug-in communication modules (e.g., PROFIBUS DP, Modbus RTU, DeviceNet). Standards & Approvals IEC/EN 60947-4-2, UL 508, CE, cULus listed.

Technical Specifications Parameter Specification Product Code PSTX250-600-70 Series ABB PSTX Medium Voltage Soft Starters Rated Voltage 3300 V / 6000 V (switch-selectable) Rated Current 250 A (continuous at 40°C) Starting Current Adjustable, typically 200% - 450% of motor FLC (Full Load Current) Motor Power Range Approx. 1400 - 1850 kW (dependent on voltage & motor characteristics) Control Supply Voltage 110-120V AC or 220-240V AC, 50/60 Hz (configurable) Starting Time Adjustable from 5 to 120 seconds Stopping Time Adjustable soft-stop (optional, 5 to 120 seconds) Cooling Method Forced air cooling (integrated fans) Enclosure IP00 / Open Type (for cabinet installation) Ambient Temperature 0°C to +40°C (32°F to 104°F) for full rating; up to +50°C (122°F) with derating Altitude Up to 1000 m (3280 ft) without derating Standards & Approvals IEC, UL, CSA, CE; compliant with IEC 60947-4-2

Technical Specifications Parameter Specification Product Code PSE60-600-70 Series ABB PSE Electronic Motor Starters Rated Operational Current (Iₑ) 60 A (at 400V, 40°C) Supply Voltage 3-phase, 380 - 690 V AC, 50/60 Hz Motor Power Range Approx. 30 - 37 kW (at 400V) Control Supply Voltage (Us) 24 V AC/DC, 48-130 V AC, 110-130 V DC, or 200-240 V AC/DC (selectable) Starting Method Voltage ramp with adjustable initial torque (kick start) and ramp time. Starting Current Adjustable, typically 200% - 400% of motor FLC. Stopping Method Coast stop (standard); Soft stop (optional, adjustable). Motor Protection Class 10 electronic overload, phase loss/imbalance, jam protection, underload, PTC thermistor input. Enclosure IP00 (Open Type) for panel mounting. Ambient Temperature -25°C to +60°C (operating), derating above +40°C. Communication Via optional plug-in modules (e.g., PROFIBUS DP, Modbus RTU). Standards & Approvals IEC/EN 60947-4-2, UL 508, CE, cULus.

Technical Specifications Parameter Specification Product Code PSE170-600-70 Series ABB PSE Electronic Motor Starters Rated Operational Current (Iₑ) 170 A (at 400V, 40°C) Rated Supply Voltage 3-phase, 380 - 690 V AC, 50/60 Hz Motor Power Range Approx. 90 - 110 kW (at 400V) Control Supply Voltage (Us) 24 V AC/DC, 48-130 V AC, 110-130 V DC, or 200-240 V AC/DC (selectable) Starting Method Voltage Ramp with adjustable initial torque and ramp time. Starting Current Adjustable, typically up to 400% of motor FLC (Full Load Current). Stopping Method Coast stop (default) or optional soft stop. Motor Protection Class 10 electronic overload protection, phase imbalance, jam/blocked rotor, underload, PTC thermistor input. Enclosure IP00 (Open Type) for mounting in a customer-supplied control cabinet. Ambient Temperature -25°C to +60°C (derating above +40°C) Communication Optional plug-in communication modules (e.g., PROFIBUS DP, Modbus RTU, DeviceNet). Standards IEC/EN 60947-4-2, UL 508, CE, cULus.

Technical Specifications Parameter Specification Product Code PSE210-600-70 Series ABB PSE Electronic Motor Starters Rated Operational Current (Iₑ) 210 A (at 400V, 40°C) Rated Supply Voltage 3-phase, 380 - 690 V AC, 50/60 Hz Motor Power Range Approx. 110 - 132 kW (at 400V) Control Supply Voltage (Us) 24 V AC/DC, 48-130 V AC, 110-130 V DC, or 200-240 V AC/DC (selectable) Starting Method Voltage Ramp with adjustable initial torque and ramp time. Starting Current Adjustable, typically up to 400% of motor FLC (Full Load Current). Stopping Method Coast stop (default) or optional soft stop. Motor Protection Class 10 electronic overload protection, phase imbalance, jam/blocked rotor, underload, PTC thermistor input. Enclosure IP00 (Open Type) for mounting in a customer-supplied control cabinet. Ambient Temperature -25°C to +60°C (derating above +40°C) Communication Optional plug-in communication modules (e.g., PROFIBUS DP, Modbus RTU, DeviceNet). Standards IEC/EN 60947-4-2, UL 508, CE, cULus.

Technical Specifications Category Likely Specification Compatibility Designed for specific series of ABB PSR (Soft Starter Combination) or MMP (Modular Motor Protector) units. The exact host device model(s) must be verified. Function Type Most Likely: A communication interface module (e.g., for PROFIBUS DP-V1 or Modbus RTU). Alternatively: An application configuration module for a specific industry/load type. Physical Interface Standardized plug connector that mates with a slot on the host device. Status Indication May include LED indicators for power, communication activity, or module status. Power Supply Powered directly from the host device (typically 24V DC derived from the main control circuit). Environmental Rated for standard industrial panel environments (IP20). Certifications Inherits safety and EMC certifications from the host system (CE, UL, cUL). 4. Key Features & Purpose System Integration: Enables the motor starter or protector to communicate with higher-level automation systems (PLCs, DCS, SCADA). Quick Commissioning: Application modules allow for rapid setup by loading pre-optimized parameter sets for common motor-driven equipment. Modularity: Allows users to select and pay only for the required functionality, with the flexibility to upgrade later. Diagnostics: Communication modules often provide enhanced diagnostic data access from the network. 5. Common Applications This module is used as a critical interface or configuration tool within motor control centers (MCCs) and automated systems: Integration into PROFIBUS DP Networks: Connecting a soft starter or motor protector to a Siemens PLC or similar control system. Pump Station Control: Using an application module pre-configured for pump control logic (soft stop, pump cleaning cycle, alternation). Fan Control Systems: Applying optimized parameters for centrifugal fan loads.

Technical Specifications Category Likely Characteristics Physical Form Small, compact printed circuit board (PCB) assembly, possibly with a plastic housing or connector interface. Compatibility Dedicated to a specific series and model of a main ABB device. Communication (If applicable) If a communication module, it might support protocols like: • PROFIBUS DP • Modbus RTU • DeviceNet • EtherNet/IP Configuration (If applicable) If a configuration module, it preloads a set of parameters for a specific motor type (e.g., high-efficiency IE3) or application (e.g., pump, fan, conveyor). Power Likely powered directly from the host/base device (e.g., 24 V DC). Environmental Rating Designed for panel-mount (IP20) industrial environments. Certifications Inherits the main system's certifications (CE, UL, cUL).

Technical Specifications Category Likely Specification Input Voltage AC Input: Likely 110-120V AC or 220-240V AC, 50/60 Hz (single or wide range). DC Input: Possibly 110-240V DC (if it's a DC/DC converter). Output Voltage Most commonly 24 V DC for industrial control circuits. Output Current / Power Typically in the range of 2.5A to 10A (60W to 240W) for a power supply module. If an interface module, it handles signal-level currents. Protection Standard features include: Overload protection, Short-circuit protection, Overvoltage protection. Efficiency High efficiency (>85%) typical for modern switched-mode power supplies. Isolation Galvanic isolation between input and output. Cooling Convection cooling (no fan). Ambient Temperature 0°C to +55°C or +60°C for full rating. Safety & EMC Standards Compliant with IEC/EN 61131-2, CE marked, UL/cUL recognized. Connection Screw-clamp terminals for reliable wiring. Status Indication LED indicator(s) for power (ON) and fault conditions.

Technical Specifications Parameter Specification Product Code PSTX570-600-70 Series ABB PSTX Medium Voltage Soft Starters Rated Voltage 3300 V / 6000 V (selectable) Rated Current 570 A (continuous at 40°C) Starting Current Adjustable, typically 200% - 500% of motor Full Load Current (FLC) Motor Power Range Approx. 3000 - 5000 kW (dependent on voltage, motor power factor, and efficiency) Control Supply Voltage 110-120V AC or 220-240V AC, 50/60 Hz Starting Time Adjustable from 5 to 120 seconds Stopping Time Adjustable soft-stop (optional, 5 to 120 seconds) Cooling Method Forced air cooling (integrated high-capacity fans) Enclosure IP00 / Open Type (for installation in a customer/contractor-supplied floor-standing or wall-mounted cabinet) Ambient Temperature 0°C to +40°C (32°F to 104°F) for full rating; up to +50°C (122°F) with derating Altitude Up to 1000 m (3280 ft) without derating Standards & Approvals IEC, UL, CSA, CE; compliant with IEC 60947-4-2

Technical Specifications Parameter Specification Product Code PSTX72-600-70 Series ABB PSTX Medium Voltage Soft Starters Rated Voltage 3300 V / 6000 V (selectable) Rated Current 72 A (continuous at 40°C) Starting Current Adjustable, typically 200% - 450% of motor FLC Motor Power Range Approx. 400 - 630 kW (dependent on voltage & motor PF) Control Supply 110-120V AC or 220-240V AC, 50/60 Hz (configurable) Starting Time Adjustable, typically 5 - 60 seconds Stopping Time Adjustable soft-stop (optional) Cooling Method Natural convection or forced air (model dependent) Enclosure IP00 / Open Chassis (for cabinet installation) Ambient Temperature 0°C to +40°C (32°F to 104°F) for full rating Altitude Up to 1000 m (3280 ft) without derating Standards IEC, UL, CSA, CE compliant

Parameter Category Specification Detail Model Designation DS7-34DSX070N0-D Product Series ABB DS7 Drive System Configuration Type Single Axis Drive Module Rated Output Current 70 A (Continuous, typical) Peak Output Current 140 A (Typically 200% of rated for short duration) Supply Voltage 3-phase, 400 - 480 V AC (+10%/-15%), 50/60 Hz DC Link Voltage 510 - 720 V DC Output Power 34 kW (Approximate, dependent on motor and application) Control Technology High-performance digital servo control with vector technology Communication Interface Integrated digital drive bus (e.g., DriveBus, SERCOS, or Ethernet-based) Feedback System Support EnDat, Hiperface, Resolver, Sin/Cos 1Vpp Control Modes Torque, Speed, Position (CSP, CSV, CST) Switching Frequency Configurable, typically 4 - 16 kHz Protection Class IP20 (Chassis unit for cabinet installation) Cooling Method Forced air cooling Ambient Temperature 0 to +45°C (32 to 113°F) for full rating; up to +55°C (131°F) with derating Relative Humidity < 95% non-condensing Standards & Approvals CE, UL, cUL, RoHS, IEC 61800-3, IEC 61800-5-1

Technical Specifications Parameter Specification Product Code PSTX300-600-70 Series ABB PSTX Medium Voltage Soft Starters Rated Voltage 3300 V / 6000 V (switch-selectable) Rated Current 300 A (continuous at 40°C) Starting Current Adjustable, typically 200-500% of motor Full Load Current (FLC) Motor Power Range Approximately 1500 - 2500 kW (dependent on voltage, motor efficiency, and application) Control Supply Voltage 110-120V AC or 220-240V AC, 50/60 Hz (configurable) Starting Time Adjustable from 5 to 120 seconds Stopping Time Adjustable from 5 to 120 seconds (soft stop option) Pulse/Triggering Advanced digital firing control Cooling Method Forced air (integrated fan cooling) Enclosure IP00 / Open Type (for installation in a customer/contractor-supplied cabinet) Ambient Temperature 0°C to +40°C (32°F to 104°F) for full rating; up to +50°C (122°F) with derating Altitude Up to 1000 m (3280 ft) without derating Standards & Approvals IEC, UL, CSA, CE; compliant with relevant sections of IEC 60947-4-2
