Technical Data Parameter Specification / Value Application Standard IEC/EN 61643-11 Protection Type / Class Type 1 + Type 2 Combined (Class I + II) System & Rated Voltage 400 V AC, 3P+N (50/60 Hz) Maximum Continuous Operating Voltage (Uc) 320 V AC (Line-Neutral) / 420 V AC (Line-Line) Impulse Discharge Current (Iimp) 10/350 µs 60 kA (per pole) Nominal Discharge Current (In) 8/20 µs 70 kA (per pole) Maximum Discharge Current (Imax) 8/20 µs 100 kA (per pole) Voltage Protection Level (Up) @ In ≤ 2.0 kV (Line-Neutral) Response Time < 100 ns Short-Circuit Withstand Rating According to IEC 61643-11 Back-up Fuse Recommendation Required. Typically 125 A or 160 A gL/gG (Consult local regulations and the official ABB installation guide). Connection Cross-Section Line & Neutral: 16 - 70 mm² (copper) Earth/PE: 25 - 70 mm² (copper) Housing Material Thermoplastic (UL94 V-0) Protection Degree (IP) IP20 (for mounting inside an enclosure) Operating Temperature Range -40 °C to +80 °C Status Indication Visual window with color flag (Green = OK, Red = Fault/End-of-Life) Mounting DIN-rail mountable (35 mm) Dimensions (H x W x D) Approx. 288 mm x 90 mm x 75 mm (Verify with latest datasheet) Key Model Decode (PSE300-600-70) PSE: Series 300: Uc & Platform Code (320/420V) 600: Iimp = 60 kA 70: In = 70 kA

Technical Data Parameter Specification / Value Application Standard IEC/EN 61643-11 Protection Type / Class Type 1 + Type 2 Combined (Class I + II) Rated Voltage (Un) 400 V AC, 3P+N (50/60 Hz) Maximum Continuous Operating Voltage (Uc) 420 V AC (Line-Line & Line-Neutral) Impulse Discharge Current (Iimp) 10/350 µs 60 kA (per pole, L/N) - This is the critical Type 1 parameter. Nominal Discharge Current (In) 8/20 µs 70 kA (per pole) Maximum Discharge Current (Imax) 8/20 µs 100 kA (per pole) Voltage Protection Level (Up) at In ≤ 2.5 kV (Line-Neutral) Response Time < 100 ns Short-Circuit Withstand Rating (SCCR) According to IEC 61643-11 Back-up Fuse Recommendation Required. Typically 160 A gL/gG or 200 A fuse per phase (MUST be verified with local regulations and the latest ABB datasheet). Connection Cross-Section Main Terminals: 35 - 95 mm² (copper) Earth Terminal: 50 - 95 mm² (copper) Housing Material Thermoplastic (UL94 V-0) Protection Degree (IP) IP20 (for indoor installation in an appropriate enclosure) Operating Temperature Range -40 °C to +80 °C Status Indication Visual (color flag: green=OK, red=fault) Mounting DIN-rail mountable (35 mm) or direct panel mounting Dimensions (H x W x D) Approx. 288 mm x 90 mm x 75 mm (Please confirm with official datasheet)

Technical Data Parameter Specification / Value (Based on PSS Series Architecture) Product Type Modular, High-Availability DC Power Supply System Input Voltage (AC) 3-phase, 400/480 V AC (Standard for this power class) Input Frequency 50/60 Hz Output Voltage (DC) 24 V DC (Nominal, adjustable) Rated Output Current The core PSS72/124 module is designed to deliver approximately 124 A per module at 24V DC. Rated Output Power Approximately ~3.0 kW per module (if 124A @ 24V). A system with multiple modules can provide significantly higher total power. Redundancy Configuration Full N+1 or N+M Redundancy supported. Modules operate in parallel with active current sharing and are hot-swappable without interrupting the output. Efficiency Very High, typically > 92% at full load. Power Factor (PF) > 0.98 (typical), minimizing reactive power demand. Protection & Monitoring Comprehensive: Overload, short-circuit, overvoltage, overtemperature. System-wide monitoring via communication interface (e.g., CANopen) and relay alarm contacts. Cooling Forced air cooling with temperature-controlled fans. Connection High-current screw terminals or busbars for input and output. Mounting / Enclosure 19-inch rack-mount modules installed in a 500mm deep cabinet (-500L). The cabinet includes integrated power distribution busbars and cooling. Operating Temperature 0°C to +60°C (with specified derating above +40°C or +50°C). Standards & Approvals CE, cULus, ATEX (for specific hazardous area variants), IEC 62368-1, IEC 62133, EN 50178.

Technical Data Parameter Specification / Value (Based on PSS Series Typical Data) Product Type Modular High-Capacity DC Power Supply System Input Voltage (AC) 3-phase, 400/480 V AC (Typical for PSS high-power modules) Input Frequency 50/60 Hz Output Voltage (DC) 24 V DC (Nominal, adjustable within a range, e.g., 24-28V) Rated Output Current The core PSS44/76 module likely provides 76 A or a similarly high current at 24V DC. The exact value must be confirmed from the official datasheet. Rated Output Power Approximately ~1.8 kW (if 76A @ 24V). Redundancy Support Yes. Modules can be configured in N+1 parallel redundancy with load sharing and hot-swap capability to ensure maximum system availability. Efficiency High efficiency, typically > 90%. Power Factor (PF) High, typically > 0.95. Protection Features Overload, overvoltage, short-circuit, and overtemperature protection. Monitoring & Signals Provides remote alarm signals (e.g., "Power Good", "Module Fail") via relay contacts or a system bus. Cooling Fan-cooled for high power dissipation. Connection Heavy-duty screw terminals for input and high-current output connections. Mounting Designed for mounting in a 19-inch rack or cabinet (the -500L likely indicates a specific cabinet depth of 500mm). Operating Temperature Typically 0°C to +60°C (with derating above a certain temperature). Approvals CE, cULus, ATEX (for hazardous areas - specific variants), IEC/EN 60950-1, IEC/EN 62133.

Technical Parameters Parameter Specification / Value Brand & Series ABB ACS510 Product Model ACS510-01-038A-4 Rated Output Power 18.5 kW (25 HP) Rated Output Current 38 A (Decoded from "038A") Input Supply Voltage 3-phase, 200–240 V AC (±10%) Input Supply Frequency 47–63 Hz Output Frequency Range 0.1–500 Hz Control Method Scalar control (V/Hz) with Automatic Energy Optimization (AEO) and enhanced motor control features. Enclosure Rating IP21 / UL Type 1 (chassis type, must be installed in a protective cabinet). Built-in EMC Filter Not Standard at this power level. Typically requires an external EMC filter (e.g., ABB RFI filter) for compliance with emission standards. Fieldbus Interface Integrated Modbus RTU (RS-485). Optional fieldbus adapters (PROFIBUS, PROFINET, etc.) available. Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) – Relay 1 Analog Input (AI) (0/4–20 mA or 0–10 V) 1 Analog Output (AO) (0/4–20 mA) Key Application Features • Dual PID controllers • Sleep/Wake & Catch a Spinning Motor • Automatic Energy Optimization (AEO) • Pump/Fan application macros • Flying Start • Customizable U/f curves Overload Capacity 110% of rated current for 60 seconds (for centrifugal loads like pumps and fans). Braking Chopper Not built-in. An external brake resistor and chopper unit are required for fast deceleration or overhauling loads. Cooling Method Forced air cooling (internal fan). Protection Features Comprehensive: Motor thermal (I²t) protection, short circuit, ground fault, over/under voltage, phase loss, drive overheating, etc. Operating Temperature -15°C to +40°C (without derating). Up to +50°C with current derating. Connection Terminals Screw terminals for power (R/L1, S/L2, T/L3, U, V, W, DC+, DC-, Brake) and control. Mounting Wall mounting (vertical orientation recommended for optimal cooling). Standards & Approvals CE, cULus, RoHS, IEC 61800-5-1, EN 61800-3.

Technical Parameters Parameter Specification / Value Brand & Series ABB ACS510 Product Model ACS510-01-09A4-4 Rated Output Power 4.0 kW (5.5 HP) Rated Output Current 9.4 A (Decoded from "09A4") Input Supply Voltage 3-phase, 200–240 V AC (±10%) Input Supply Frequency 47–63 Hz Output Frequency Range 0.1–500 Hz Control Method Scalar control (V/Hz) with Automatic Energy Optimization (AEO) Enclosure Rating IP21 / UL Type 1 (chassis type, for cabinet mounting) Built-in EMC Filter Yes, Class A (standard) Fieldbus Interface Integrated Modbus RTU (RS-485) Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) – Relay 1 Analog Input (AI) (0/4–20 mA or 0–10 V) 1 Analog Output (AO) (0/4–20 mA) Key Application Features • Dual PID controllers • Sleep/Wake function • Flying start • Pump & fan macros • Custom U/f curves Overload Capacity 110% of rated current for 60 s (suited for centrifugal loads) Braking Chopper Not internal; external brake resistor supported Protection Features Motor thermal (I²t), short circuit, ground fault, over/under voltage, phase loss, etc. Operating Temperature –15°C to +40°C (full rating) / up to +50°C with derating Mounting Wall or DIN rail (with optional adapter) Standards & Approvals CE, cULus, RoHS, IEC 61800‑5‑1, EN 61800‑3

Technical Parameters Parameter Specification / Value Brand & Series ABB ACS510 Product Model ACS510-01-07A2-4 Rated Output Power 3.0 kW (4.0 HP) Rated Output Current 7.2 A (Decoded from the "07A2" current code) Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz) with Automatic Energy Optimization (AEO) Enclosure Rating IP21 / UL Type 1 (Chassis Type) Built-in EMC Filter Yes, Class A (Standard) Fieldbus Interface Integrated Modbus RTU (via RS-485) Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Key Application Features • Dual PID Controllers • Sleep/Wake Function • Flying Start • Pump & Fan Application Macros Overload Capacity 110% of rated current for 60 seconds Braking Chopper Not internal. Supports external brake resistor. Protection Features Motor thermal (I²t), short circuit, ground fault, over/under voltage, phase loss, etc. Operating Temperature -15°C to +40°C (full rating) / Up to +50°C with derating Mounting Wall or DIN rail mountable (with adapter) Standards & Approvals CE, cULus, RoHS, IEC 61800-5-1, EN 61800-3

Technical Data Parameter Specification / Value Drive Series & Model ABB ACS510 General Purpose Drive Product Code ACS510-01-05A6-4 Rated Output Power 2.2 kW (3.0 HP) Rated Output Current 5.6 A (Decoded from "05A6": 05 = 5.x Amps, A=6 in hex, so 5.6A) Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) (*The "-01" suffix specifies this voltage range*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz) with advanced motor control enhancements. Enclosure Class IP21 / UL Type 1 (Chassis Type). Designed for mounting inside a protective electrical enclosure. Built-in Standard EMC Filter Yes, Class A (Industrial environment). Fieldbus Interface Integrated Modbus RTU (RS-485). Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (configurable as 0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Key Application Features • Dual Independent PID Controllers • Sleep/Wake & Catch a Spinning Motor • Auto Energy Optimization (AEO) • Customizable U/F Curves (e.g., quadratic for fans) • Flying Start Overload Capacity 110% of rated current for 60 seconds (suited for centrifugal pump/fan loads). Braking Chopper Not internally integrated. Requires an external brake resistor module for applications requiring fast deceleration or overhauling loads. Protection Features Full suite: Motor thermal (I²t) protection, overcurrent, short circuit, ground fault, over/under voltage, input phase loss, etc. Operating Temperature -15°C to +40°C (without derating). Up to +50°C with current derating. Storage Temperature -40°C to +70°C Relative Humidity < 95% RH, non-condensing Mounting Wall mounting or on DIN rail (using optional adapter). Approvals & Standards CE, cULus, RoHS, IEC 61800-5-1, EN 61800-3.

Technical Data Parameter Specification / Value Drive Series & Model ABB ACS510 General Purpose Drive Product Code ACS510-01-04A1-4 Rated Output Power 1.5 kW (2.0 HP) Rated Output Current 4.1 A (This aligns with the "04A1" code: 04 = 4.x Amps, 1 = .1) Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) (*The "-01" denotes this specific low-voltage range*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz - V/Hz) with flux optimization. Enclosure Class IP21 / UL Type 1 (Chassis Type). Requires installation in a proper enclosure for full protection. Built-in Standard EMC Filter Yes, Class A (Standard). Limits electromagnetic interference. Fieldbus Interface Integrated Modbus RTU via RS-485. Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Key Application Features • Dual PID Controllers • Sleep/Wake Function • Flying Start • Auto Energy Optimization (AEO) • Pump/Fan-specific curves Overload Capacity 110% of rated current for 60 seconds (Light overload capacity, suitable for centrifugal loads). Braking Chopper Not built-in. Supports connection of an external brake resistor for deceleration or holding loads. Protection Features Comprehensive: Motor thermal (I²t) overload, short circuit, ground fault, overvoltage, undervoltage, phase loss, etc. Operating Temperature -15°C to +40°C (full rated output). Up to +50°C with derating. Storage Temperature -40°C to +70°C Relative Humidity < 95% RH, non-condensing Mounting Wall mounting or on DIN rail (with optional adapter kit). Approvals & Standards CE, cULus, RoHS, compliant with IEC 61800-5-1, EN 61800-3.

Technical Data Parameter Specification / Value Drive Series & Model ABB ACS510 General Purpose Drive Product Code ACS510-01-03A3-4 Rated Output Power 1.1 kW (1.5 HP) Rated Output Current 3.0 A (This aligns with the "03A3" code: 03 = 3.0 Amps) Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) (*Note: The "-01" in the model typically indicates this 200-240V range*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz - V/Hz) with energy-saving optimization. Enclosure Class IP21 / UL Type 1 (Chassis Type). Provides basic finger and drip protection. Must be installed in a suitable cabinet for full environmental protection. Built-in Standard EMC Filter Yes, Class A. Limits conducted and radiated emissions for industrial environments. Fieldbus Interface Integrated Modbus RTU via RS-485. Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (configurable as 0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Key Application Features • PID Controller (2 independent sets) • Sleep/Wake Function • Flying Start • Auto Energy Optimization Overload Capacity 110% of rated current for 60 seconds (for light-duty applications like pumps/fans). Braking Chopper Not built-in. An external brake resistor can be connected for dynamic braking requirements. Protection Features Motor thermal (I²t) protection, overcurrent, overvoltage, undervoltage, short circuit, ground fault, etc. Operating Temperature -15°C to +40°C (without derating). Up to +50°C with current derating. Storage Temperature -40°C to +70°C Relative Humidity < 95% RH, non-condensing Mounting Wall or DIN rail mounting (with optional adapter) Approvals & Standards CE, cULus, RoHS, compliant with IEC 61800-5-1, EN 61800-3

Technical Data Parameter Specification / Value Product Name Control Panel, Hand-held Compatible Drive Series ACX Series Drives: ACS150, ACS310, ACS355, and other drives sharing the same control panel interface. Display LCD with backlight, 4 lines of text. Keys Navigation keys (Up, Down, Left, Right, OK), Function keys (F1, F2, F3), Stop/Reset key, Drive control keys. Power Supply Powered directly from the connected drive via the interface cable. No separate power source required. Connection Interface Dedicated plug for the drive's control panel port (CN1/A on compatible drives). Connection Cable Typically uses a specific cable (e.g., ABB Connection Kit JZRPS-312C). The cable length varies (common lengths: 3m, 10m). Main Functions 1. Parameter Handling: View, edit, save, upload, and download drive parameters. 2. Drive Control: Local Start, Stop, Jog, Change direction, and reference setting. 3. Monitoring: Real-time display of speed, current, frequency, DC voltage, I/O status, faults, and warnings. 4. Fault Management: View fault history and reset faults. Parameter Copy Yes. Can store the complete parameter set of one drive in its memory and transfer it to another identical drive model, saving commissioning time. Language Support Multiple languages supported in the display menu (English, German, French, Spanish, Italian, etc.). Storage Temperature -25°C to +70°C Operating Temperature 0°C to +50°C (for reliable operation) Relative Humidity 5% to 95%, non-condensing Dimensions (Approx.) ~190 mm x 100 mm x 40 mm (H x W x D) - Hand-held size. Order Reference The complete kit is often ordered as JZRPS-312 (which includes the CDP 312R panel and a connection cable).

Technical Data Parameter Specification / Value Drive Series & Model ABB ACS355 General Purpose Drive Product Code ACS355-03E-31A0-4 Rated Output Power 1.1 kW (1.5 HP) Rated Output Current 3.1 A Input Supply Voltage 3-phase, 380 - 480 V AC (±10%) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Methods Scalar Control (Volts/Hertz) for standard applications. Enclosure Class IP20 / UL Type 1 (Chassis Type) - For mounting inside a control cabinet for protection. Built-in EMC Filter Yes, Class A (for industrial environments). Limits conducted emissions. Built-in DC Choke Yes (on this model). Reduces input current harmonics and improves drive reliability. Fieldbus Interface Integrated Modbus RTU (via RS-485). Digital/Analog I/O 2 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Overload Capacity 150% of rated current for 60 seconds. Braking Chopper Not built-in. Requires an external brake resistor for dynamic braking. Safety Function Safe Torque Off (STO) via an optional connection kit. Protection Features Motor thermal overload, overcurrent, overvoltage, undervoltage, short circuit, ground fault, etc. Operating Temperature -15°C to +50°C (without derating). Up to +40°C at full rated current. Storage Temperature -40°C to +70°C Relative Humidity < 95% RH, non-condensing Mounting Wall or DIN rail mounting (with optional adapter) Approvals & Standards CE, cULus, RoHS, compliant with IEC 61800-5-1, EN 61800-3
