Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS150 General Purpose Drive Product Code ACS150-03E-05A6-4 Rated Output Power 2.2 kW (3.0 HP) Rated Output Current 5.6 A (Decoded from "05A6") Input Supply Voltage 3-phase, 380 - 480 V AC (±10%) (*The "-03E" indicates this voltage range and frame size*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.5 - 500 Hz Control Method Basic Scalar Control (Volts/Hertz). Enclosure Class IP20 / UL Type 1 (Chassis Type). Must be installed in a protective enclosure. Built-in EMC Filter Not Standard. An external EMC filter is typically required for compliance in industrial environments. Fieldbus Interface None. Control is exclusively via hard-wired terminals. Digital/Analog I/O 2 Digital Inputs (DI) 1 Relay Output (RO) 1 Analog Input (AI) (0-10 V) Key Functions • Adjustable acceleration/deceleration times • DC injection braking • 2 preset speeds • Motor thermal protection (I²t) Overload Capacity 150% for 60 seconds. Braking Chopper Not supported. Cannot use a dynamic braking resistor. Safety Function None standard. Protection Features Motor thermal overload, overcurrent, short circuit, ground fault, overvoltage, undervoltage, phase loss. Operating Temperature -10°C to +40°C (without derating). Storage Temperature -40°C to +70°C Mounting DIN-rail mounting (35 mm) or wall mounting. Approvals & Standards CE, cULus, RoHS

Technical Parameters Parameter Specification / Value (Typical Range) Part Type Medium Voltage Vacuum Contactor Module / Repair Kit ABB Material Code 1SAP1207G0001 Rated Voltage (Ur) 7.2 kV or 12 kV (System dependent) Rated Frequency 50 / 60 Hz Rated Normal Current (Ir) 400 A, 630 A, or 1250 A (Common ratings) Rated Short-Time Withstand Current (Ik) 25 kA or 31.5 kA for 3 seconds Rated Making Current 63 kA or 80 kA peak Rated Breaking Current 25 kA or 31.5 kA RMS Mechanical Life 30,000 - 50,000 operations Electrical Life 10,000 - 20,000 operations at rated current Operating Mechanism Spring-charged, motor or solenoid operated Control Voltage 110 V DC or 220 V DC (Common for spring charging motor) Auxiliary Contacts Multiple NO/NC contacts for control and indication Interlock System Mechanical interlocks for safety and sequence control Standards IEC 62271-100, IEC 62271-1, ANSI C37.04

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS150 General Purpose Drive Product Code ACS150-01E-03A5-2 Rated Output Power 1.1 kW (1.5 HP) Rated Output Current 3.5 A (Decoded from "03A5") Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) (*The "-01E" indicates this voltage range and frame size*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.5 - 500 Hz Control Method Basic Scalar Control (Volts/Hertz). Enclosure Class IP20 / UL Type 1 (Chassis Type). Must be installed in a protective enclosure. Built-in EMC Filter Not Standard. An external EMC filter is typically required for compliance. Fieldbus Interface None. Control is via hard-wired terminals only. Digital/Analog I/O 2 Digital Inputs (DI) 1 Relay Output (RO) 1 Analog Input (AI) (0-10 V) Key Functions • Adjustable acceleration/deceleration times • DC injection braking • 2 preset speeds • Motor thermal protection (I²t) Overload Capacity 150% for 60 seconds. Braking Chopper Not supported. Cannot use a dynamic braking resistor. Safety Function None standard. Protection Features Motor thermal overload, overcurrent, short circuit, ground fault, overvoltage, undervoltage, phase loss. Operating Temperature -10°C to +40°C (without derating). Storage Temperature -40°C to +70°C Mounting DIN-rail mounting (35 mm) or wall mounting. Approvals & Standards CE, cULus, RoHS.

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS150 General Purpose Drive Product Code ACS150-01E-02A4-2 Rated Output Power 0.75 kW (1.0 HP) Rated Output Current 2.4 A (Decoded from "02A4": likely 2.4 A) Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) (*The "-01E" denotes this voltage range and frame size*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.5 - 500 Hz Control Method Basic Scalar Control (Volts/Hertz). Enclosure Class IP20 / UL Type 1 (Chassis Type). Must be installed in a protective enclosure. Built-in EMC Filter Not Standard. An external EMC filter is typically required for compliance in industrial environments. Fieldbus Interface None. Control is via hard-wired terminals only. Digital/Analog I/O 2 Digital Inputs (DI) 1 Relay Output (RO) 1 Analog Input (AI) (0-10 V) Key Functions • Adjustable acceleration/deceleration ramps • Limited preset speeds • DC injection braking • Basic motor thermal protection Overload Capacity 150% for 60 seconds (typical). Braking Chopper Not supported. Cannot connect a dynamic braking resistor. Safety Function None standard. Protection Features Basic: Motor thermal overload (I²t), overcurrent, short circuit, ground fault, overvoltage, undervoltage. Operating Temperature -10°C to +40°C (without derating). Storage Temperature -40°C to +70°C Mounting DIN-rail mounting (35 mm) Approvals & Standards CE, cULus, RoHS.

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS310 General Purpose Drive Product Code ACS310-03E-02A6-4 Rated Output Power 1.1 kW (1.5 HP) Rated Output Current 2.6 A (Decoded from "02A6") Input Supply Voltage 3-phase, 380 - 480 V AC (±10%) (*The "-03E" denotes this voltage range and frame size*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz - V/Hz) with basic optimization features. Enclosure Class IP20 / UL Type 1 (Chassis Type). Must be installed in a suitable enclosure (e.g., IP54 cabinet). Built-in EMC Filter Yes, Class A (Standard for industrial environments). Fieldbus Interface Integrated Modbus RTU via RS-485. Digital/Analog I/O 3 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Application Features • Pre-programmed application macros (Pump, Fan) • Sleep/Wake function (optional via macro) • Flying Start • DC braking Overload Capacity 150% of rated current for 60 seconds. Braking Chopper Not built-in. Supports connection of an external brake resistor (requires optional brake chopper unit). Safety Function Safe Torque Off (STO) via an optional connection kit. Protection Features Motor thermal overload (I²t), overcurrent, short circuit, ground fault, overvoltage, undervoltage, phase loss. Operating Temperature -10°C to +50°C (without derating). Up to +40°C at full rated current. Storage Temperature -40°C to +70°C Mounting Wall or DIN rail mounting (with optional adapter). Approvals & Standards CE, cULus, RoHS, compliant with IEC 61800-5-1, EN 61800-3.

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS350 Compact Drive Product Code ACS350-03E-01A9-4 Rated Output Power 0.37 kW (0.5 HP) Rated Output Current 1.9 A (Decoded from "01A9": 01 = 1.x A, A=10, 9=0.9, so 1.9 A) Input Supply Voltage 3-phase, 380 - 480 V AC (±10%) (*The "-03E" denotes this voltage range and frame size*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz - V/Hz). Enclosure Class IP20 / UL Type 1 (Chassis Type). Must be installed in a protective enclosure. Built-in EMC Filter Typically Not Standard at this micro size. An external filter is recommended/required for EMC compliance. Fieldbus Interface Integrated Modbus RTU via RS-485. Digital/Analog I/O 2 Digital Inputs (DI) 1 Digital Output (DO) - Transistor 1 Analog Input (AI) (0-10 V) 1 Analog Output (AO) (0-20 mA) Overload Capacity 150% of rated current for 60 seconds. Braking Chopper Not built-in. Does not support dynamic braking with a resistor. Safety Function Safe Torque Off (STO) via an optional connection kit. Protection Features Motor thermal overload, overcurrent, short circuit, ground fault, overvoltage, undervoltage. Operating Temperature -10°C to +40°C (without derating). Storage Temperature -40°C to +70°C Mounting DIN-rail mounting (35 mm) Dimensions (WxHxD) Very compact, approximately 45 x 145 x 140 mm (verify with datasheet). Approvals & Standards CE, cULus, RoHS, IEC 61800-5-1.

Technical Parameters Parameter Specification / Value (Inferred) Product Series ABB MFE Series Motor Starter Product Code MFE180-04AN-046A-4 Starter Type Direct-On-Line (DOL) Starter (or possibly a basic Soft Starter variant). Rated Operational Power ~18.5 kW (25 HP) at 400V AC (Inferred from frame/current code) Rated Operational Current (Ie) 46 A (at 400V AC, 3-phase) Utilization Category AC-3 (for squirrel-cage motors: starting, switching off) Rated Insulation Voltage (Ui) 690 V AC Rated Thermal Current (Ith) 55 A (typical for 46A Ie rating) Overload Relay Setting Range Likely adjustable within a range (e.g., 40-55 A). Trip Class Class 10 (standard for motor protection). Coil Control Voltage (Us) 230V AC, 50/60 Hz (Common for 04AN code). Must be verified via datasheet. Enclosure Protection IP65 (Typical for enclosed starters). Connection Screw terminals for main power and control wiring. Auxiliary Contacts Typically includes at least 1 NO + 1 NC auxiliary contact. Ambient Temperature -25°C to +60°C (operating). Mounting Surface mounting (on wall or panel). Standards IEC/EN 60947-4-1, IEC/EN 60947-5-1, CE, cULus. Model Decoding (Interpretation) MFE180: Series and design platform. 04AN: Likely indicates coil voltage and specific features. 046A: Rated operational current = 46 Amps. 4: Enclosure type/hardware version.

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS355 Compact Drive Product Code ACS355-03U-05A6-4 Rated Output Power 2.2 kW (3.0 HP) Rated Output Current 5.6 A (Output, three-phase) Input Supply Voltage 1-phase, 200 - 240 V AC (±10%) (*The "-03U" denotes Single-Phase Input in the 200-240V range*) Input Current Approx. 16-18 A (at rated load, single-phase - consult datasheet) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (Volts/Hertz - V/Hz). Enclosure Class IP21 / UL Type 1 (Chassis Type). Must be installed in a suitable enclosure. Built-in EMC Filter Yes, Class A (Standard). Built-in DC Choke Yes (Standard on this model). Fieldbus Interface Integrated Modbus RTU via RS-485. Digital/Analog I/O 2 Digital Inputs (DI) 1 Digital Output (DO) - Relay 1 Analog Input (AI) (0/4-20 mA or 0-10 V) 1 Analog Output (AO) (0/4-20 mA) Overload Capacity 150% of rated current for 60 seconds. Braking Chopper Not built-in. Requires an external brake resistor for dynamic braking. Safety Function Safe Torque Off (STO) via an optional connection kit. Protection Features Motor thermal overload (I²t), overcurrent, overvoltage, undervoltage, short circuit, ground fault, etc. Operating Temperature -15°C to +50°C (without derating). Up to +40°C at full rated current. Mounting Wall or DIN rail mounting (with optional adapter) Approvals & Standards CE, cULus, RoHS, compliant with IEC 61800-5-1, EN 61800-3.

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS550 General Purpose Drive Product Code ACS550-01-015A-4 Package Option +B055 (Mounting/Accessory Kit) Rated Output Power 4.0 kW (5.5 HP) Rated Output Current 15 A Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) Input Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (V/Hz) with Automatic Energy Optimization (AEO) Enclosure Class IP21 / UL Type 1 (Chassis) Built-in EMC Filter Class A (Standard) Fieldbus Interface Modbus RTU (RS-485) Digital/Analog I/O 3 DI, 1 Relay DO, 1 AI, 1 AO Key Application Features • PID controller • Sleep/Wake function • Flying Start • Pump & Fan application macros Overload Capacity 110% for 60 seconds Braking External brake resistor supported (chopper not built-in) Protection Features Motor thermal (I²t), short circuit, ground fault, over/under voltage, phase loss Operating Temperature -10°C to +40°C (full rating) Storage Temperature -40°C to +85°C Mounting Wall mount with B055 kit B055 Kit Contents Mounting bracket, screws, installation hardware, possibly cable glands Dimensions (Drive only) ~ 220 x 245 x 195 mm (HxWxD) - Confirm with datasheet Weight Approx. 4.2 kg (drive only) Approvals CE, cULus, RoHS, IEC 61800-5-1

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS150 General Purpose Drive Product Code ACS150-03E-07A3-4 Rated Output Power 3.0 kW (4.0 HP) Rated Output Current 7.3 A (Decoded from "07A3") Input Supply Voltage 3-phase, 380 - 480 V AC (±10%) (*The "-03E" denotes this voltage range and frame size*) Input Supply Frequency 47 - 63 Hz Output Frequency Range 0.5 - 500 Hz Control Method Basic Scalar Control (Volts/Hertz). Enclosure Class IP20 / UL Type 1 (Chassis Type). Must be installed in a protective enclosure. Built-in EMC Filter Not Standard. An external EMC filter is typically required for compliance in industrial environments. Fieldbus Interface None (Standard). Control is via hard-wired terminals only. Digital/Analog I/O 2 Digital Inputs (DI) 1 Relay Output (RO) 1 Analog Input (AI) (0-10 V) (Configuration is minimal) Key Functions • Adjustable acceleration/deceleration ramps • Limited preset speeds • DC injection braking • Basic motor thermal protection Overload Capacity 150% for 60 seconds (typical). Braking Chopper Not supported. Cannot connect a dynamic braking resistor. Safety Function None standard. Protection Features Basic: Motor thermal overload (I²t), overcurrent, short circuit, ground fault, overvoltage, undervoltage. Operating Temperature -10°C to +40°C (without derating). Storage Temperature -40°C to +70°C Mounting DIN-rail mounting (35 mm) or wall mounting. Approvals & Standards CE, cULus, RoHS

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS510 General Purpose Drive Product Code ACS510-01-038A-4 Package Option +B055 (Mounting/Accessory Kit) Rated Output Power 18.5 kW (25 HP) Rated Output Current 38 A Input Supply Voltage 3-phase, 200 - 240 V AC (±10%) Input Frequency 47 - 63 Hz Output Frequency Range 0.1 - 500 Hz Control Method Scalar Control (V/Hz) with AEO Enclosure Class IP21 / UL Type 1 (Chassis) Built-in EMC Filter Class A (Standard) Fieldbus Interface Modbus RTU (RS-485) Digital/Analog I/O 3 DI, 1 Relay DO, 1 AI, 1 AO Key Functions PID control, Sleep/Wake, Flying Start, Pump/Fan curves Overload Capacity 110% for 60 seconds Braking External brake resistor supported Protection Features Motor thermal, short circuit, ground fault, over/under voltage Operating Temperature -15°C to +40°C (full rating) Mounting Wall mount (with B055 kit) B055 Kit Contents Mounting bracket, hardware, possibly cable glands or connectors Approvals CE, cULus, RoHS, IEC 61800-5-1

Technical Parameters Parameter Specification / Value Drive Series & Model ABB ACS380 Modular Drive Product Code ACS380-042S-02A6-4 Rated Output Power 1.1 kW (1.5 HP) Rated Output Current 2.6 A (Output, three-phase) Input Supply Voltage 1-phase, 200 - 240 V AC (±10%) (*The "042S" denotes single-phase input and slot-in type*) Input Current Approx. 12 A (at rated load, single-phase) Input Supply Frequency 50/60 Hz Output Frequency Range 0 - 500 Hz Control Method Sensorless Vector Control (DTC-based) for high starting torque and accurate speed regulation. Embedded PLC Yes, programmable via Drive composer software (IEC 61131-3). Enclosure Class IP20 / UL Type 1 (for mounting inside a protected enclosure). Built-in Standard I/O 3 Digital Inputs (DI), 1 Digital Output (DO), 1 Analog Input (AI), 1 Analog Output (AO), 2 Relay Outputs. Modular Expansion Slots 2 slots for optional modules (e.g., I/O, fieldbus cards, Safe Torque Off, encoder interface). Standard Communication Modbus RTU (RS-485). Fieldbus options via plug-in cards (PROFIBUS, PROFINET, EtherNet/IP, etc.). Overload Capacity 150% for 60 seconds. Braking Built-in braking chopper standard (for connecting external brake resistor). Safety Function Option for plug-in Safe Torque Off (STO) module. Operating Temperature -15°C to +40°C (without derating). Mounting Slot-in mounting on DIN-rail (35 mm) with optional mounting frame. Dimensions (WxHxD) Very compact (e.g., ~ 70 x 200 x 190 mm – verify with datasheet). Approvals & Standards CE, cULus, RoHS, IEC 61800-5-1.
