Key Specifications) Parameter Category Specification Drive Series/Base Model ACS355-03E-08A8-4 Rated Output Current 8.0 A Rated Output Power 3.0 kW (4 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP20 / UL Open Type (Chassis). Control Panel Removable Control Panel (RCP) with backlit LCD. Cooling Method Self-cooled (with internal fan) Control Methods • Scalar Control (V/f) • ABB Direct Torque Control (DTC) Key Standard Features • Removable Control Panel (RCP). • Built-in EMC Filter (Class A). • Application Macros (Factory, Hand/Auto, Pump/Fan). • Built-in PID Controller. • Built-in Modbus RTU (RS-485). • Basic I/O: 2 analog inputs, 1 analog output; 3 digital inputs, 1 relay output. Option +B063 Embedded PROFIBUS DP-V1 Adapter Module • Protocol: PROFIBUS DP-V1 (符合 EN 50170). Protection Features • Motor thermal overload protection (I²t) • Short circuit, ground fault, overcurrent, overvoltage protection • IGBT overtemperature protection Application Focus General industrial machinery (Pumps, Fans, Conveyors) within PROFIBUS DP networked automation systems, commonly found with Siemens PLCs.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS380-040C-12A6-4 Rated Output Current 12.6 A Rated Output Power 5.5 kW (7.5 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating NEMA 1 / IP20 Open Type (Chassis). Requires installation in a protective cabinet. Cooling Method Shaft-through fan cooling (indicated by 'C' in -040C) Control Method Sensorless Flux Vector Control (Magnetic Flux Control, MFC) Key Standard Features • Material Handling Macros: Pre-programmed for conveyors, hoists. • Dynamic Braking Control: Logic for external brake resistors. • Torque Control & Limits: For tension control and overload prevention. • S-curve Acceleration/Deceleration. • Removable Control Panel (RCP) with backlit display. • Integrated EMC Filter (Class A). • Built-in Modbus RTU (RS-485). Option +K475 Embedded EtherNet/IP Adapter Module • Protocol: EtherNet/IP™ (Scanner/Adapter). • Ports: 2 x RJ45 (10/100 Mbps), switchable. • Function: Enables direct, high-speed integration into EtherNet/IP networks for control (I/O messaging) and configuration (explicit messaging). Allows seamless connection to Rockwell Automation PLCs (ControlLogix, CompactLogix) and other EtherNet/IP masters. Protection Features • Motor thermal and electrical protection. • Drive IGBT overtemperature protection. • Motor stall/underload protection. Application Focus Conveyor systems, sorting lines, palletizers, small cranes/hoists, and other material handling equipment within EtherNet/IP networked factories.

Key Specifications Parameter Category Specification Drive Series/Model ACS320-03U-14A6-2 Rated Output Current 14.6 A Rated Output Power 4.0 kW (5 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Must be installed inside a protective control cabinet (e.g., IP20, IP54). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Method Sensorless Vector Control Key Standard Features • Ultra-Compact & Sealed Design: All-in-one unit with a durable keypad for harsh environments. • Easy Mounting: Snap-on design for DIN rail or screw mounting. • Application Macros: Pre-set configurations for common tasks (e.g., Hand/Auto, 2-Wire, 3-Wire). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Digital Inputs: 3 channels. • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication via an optional external module (e.g., NAMC-01). Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small conveyors, pumps, fans, packaging machines, and other general-purpose material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Model ACS355-01E-07A5-2 Rated Output Current 7.5 A Rated Output Power 2.2 kW (3 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 1-phase Input Supply Phases 1-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP20 / UL Open Type (Chassis). Must be installed inside a protective control cabinet. Control Panel Removable Control Panel (RCP) with backlit LCD. Cooling Method Self-cooled (convection) Control Methods • Scalar Control (V/f) for standard applications. • ABB Direct Torque Control (DTC) for high dynamic performance (precise torque control, fast response). Key Standard Features • Removable Control Panel (RCP): Allows for remote mounting and easy parameter copy. • Built-in EMC Filter (Class A). • Application Macros: Pre-programmed parameter sets for common tasks (Factory, Hand/Auto, Pump/Fan). • Built-in PID Controller with sleep/wake function. • Flying Start and DC Magnetization. • Built-in I/O: 2 analog inputs (0/4...20 mA, 0...10 V), 1 analog output; 3 digital inputs, 1 relay output. • Fieldbus Connectivity: Built-in Modbus RTU (RS-485); optional adapters for PROFIBUS DP, DeviceNet, CANopen, etc. Protection Features • Motor thermal overload protection (I²t) • Short circuit, ground fault, overcurrent, and overvoltage protection • Motor stall and underload protection • IGBT overtemperature protection • Power loss ride-through Application Focus General-purpose industrial machinery (Pumps, Fans, Conveyors, Mixers, Packaging machines).

Key Specifications Parameter Category Specification Product Type Digital Servo Drive / Servo Amplifier ABB Series / Model ACSM1-04AS-07A0-4 Rated Output Current 7.0 A RMS (Continuous) Peak Output Current Typically 14 A (for short durations, e.g., 100% overload). Rated Output Power 2.2 kW (with a compatible motor) Input Supply Voltage 380 - 480 V AC (±10%), 3-phase, 50/60 Hz DC Bus Voltage ~540 - 680 V DC Output Phases 3-phase to motor (U, V, W) Control Technology Field-Oriented Control (FOC) / Vector Control Feedback Interface Supports high-resolution encoders (e.g., EnDat 2.2, HIPERFACE®, Resolver, Sin/Cos). Key Standard Features • Integrated Motion Controller: Programmable via ABB's Motion Desktop software. • Integrated Safety: Safe Torque Off (STO) according to SIL 2/PL d (or SIL 3/PL e). • Fieldbus Connectivity: Built-in EtherCAT master/slave interface for high-speed network integration. PROFINET and others via optional modules. • Compact Design: High power density for cabinet mounting. • Extensive I/O: Digital and analog I/O for sensors and control signals. Protection Features • Overcurrent, short circuit, ground fault protection. • IGBT overtemperature protection. • Motor overload and overspeed protection. • Undervoltage and overvoltage protection on DC bus. Application Focus High-precision industrial automation: Robotics, Packaging Machinery, Material Handling, Printing, Machine Tools, Assembly Systems.

Key Specifications Parameter Category Specification Drive Series/Model DCS800-S02-0075-05-0 Motor Type DC Motor (Armature & Field Supply) Rated Armature Current 75 A (Continuous DC Output) Rated Power Output ~34 kW (for a typical 460V DC motor: 75A * 460V ≈ 34.5 kW) Configuration Single Quadrant (S02): Forward motoring operation only. Cannot handle regenerative energy. Power Input Typically 3-phase, 400V AC (±10%), 50/60 Hz. (Confirm based on "-05" code). Armature Output Voltage Variable DC, typically up to ~500V DC for a 400V AC supply. Field Supply Output Separate, adjustable DC output for the motor's field winding. Control Method Digital, using thyristor (SCR) converter technology. Features current and speed feedback loops. Key Features • Digital Control Unit (DCU): Programmable via Control Panel or DriveWindow software. • Precise Speed Regulation with tachometer or EMF feedback. • Torque Control capability. • Extensive I/O for process integration. • Field Weakening capability for extended speed range. Protection Features • Armature and field overcurrent protection. • Motor thermal overload protection. • Mains phase loss and undervoltage protection. • Overvoltage and over-speed protection. • Heatsink overtemperature protection. Typical Applications Extruders, Winders/Unwinders, Mixers, Machine Tools, Presses, and other machinery using DC motors where single-quadrant control is sufficient.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS530-01-073A-4 Rated Output Current 73 A Rated Output Power 37 kW (50 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 (Indoor, cabinet/wall mounting) Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Graphical Control Panel: Plain-language display for easy setup. • Application Macros: Pre-set for Pump, Fan, Hand/Auto, etc. • Built-in EMC Filter (Class A). • Built-in Modbus RTU (RS-485). • PID Controller with advanced functions. • Flying Start and Automatic Motor Adaptation (AMA). Option +J400 Conformal Coating (PCB Protection) • Function: Applies a thin, protective polymeric film to the circuit boards. • Protection Against: Moisture, condensation, dust, salts, mild chemical vapors, and fungal growth. • Benefit: Significantly increases drive reliability and service life in harsh, corrosive, or high-humidity environments. Protection Features • Standard electrical and thermal protection for motor and drive. • Enhanced environmental protection for PCBs via the +J400 coating. Application Focus General-purpose industrial applications (pumps, fans, conveyors) installed in harsh environments such as wastewater plants, chemical facilities, coastal areas, food processing, and washdown areas.

Key Specifications Parameter Category Specification Drive Series/Model ACS530-01-145A-4 Rated Output Current 145 A Rated Output Power 75 kW (100 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Graphical Control Panel: Plain-language, backlit display with navigation keys for easy setup. • Application Macros: Pre-defined parameter sets (Pump, Fan, Hand/Auto, etc.) for fast commissioning. • Built-in EMC Filter (Class A) • Built-in Modbus RTU (RS-485) serial communication • PID Controller with sleep/wake and anti-jam functions • Flying Start and Automatic Motor Adaptation (AMA) Protection Features • Motor thermal overload protection (I²t) • Short circuit, ground fault, overcurrent, and overvoltage protection • Motor stall and underload protection • IGBT overtemperature protection • Power loss ride-through Application Focus Heavy-duty industrial applications (Large Pumps, Fans, Compressors, Conveyors, Mixers).

Key Specifications Parameter Category Specification Product Type Motor Start Capacitor (Electrolytic or AC Film type, typically non-polarized for AC operation) ABB Order Code / Part Number 1SFA897109R7000 Capacitance 70 µF (Microfarads) - This is the most common value indicated by the "70" in the suffix "R7000". Rated Voltage ~250 V AC / 370 V DC (or similar, e.g., 300/330 V AC). Crucial: Must match or exceed the motor's operating voltage. Frequency 50/60 Hz Tolerance Typically ±5% or ±10% Operating Temperature Range Typically -25°C to +70°C (common for motor start capacitors) Duty Cycle Intermittent Duty (Start Duty). Designed for short-duration energization during motor start-up (a few seconds), not for continuous run operation. Case Type Typically a cylindrical metal or plastic can with insulated terminals. Terminal Type Usually spade terminals (6.3 x 0.8 mm quick-connect) or screw terminals. Key Function Provides the necessary phase shift in the auxiliary winding circuit to create a starting torque for single-phase induction motors.

Key Specifications Parameter Category Specification Drive Series/Model ACS150-01E-04A7-2 Rated Output Current 4.7 A Rated Output Power 1.1 kW (1.5 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 1-phase Input Supply Phases 1-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP20 / UL Open Type (Chassis). Must be installed inside a protective control cabinet. Control Panel Standard removable keypad (non-sealed), supports remote mounting. Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Removable Keypad: Can be mounted remotely on the cabinet door. • Flexible Mounting: DIN rail or screw mounting. • Application Macros: Pre-set parameter sets (Hand/Auto, 2-Wire, 3-Wire, etc.). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) available via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, conveyors, and basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Base Model ACH550-01-246A-4 Rated Output Current 246 A Rated Output Power 132 kW (175 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 (Indoor, cabinet mounting) Cooling Method Fan-cooled Control Method ABB's Sensorless Flux Control (Magnetizing Flux Control, MFC) for HVAC. Key Standard Features • HVAC-Optimized Software: Advanced PID, multi-pump/fan control logic (lead/lag). • Built-in Building Protocols: BACnet MS/TP and Metasys N2 standard, plus Modbus RTU. • Energy Optimizer: Automatically minimizes losses for peak efficiency. • LCD Keypad with multi-language support. • Extended Safety: Fireman’s Override, smoke control sequences. Option +B055 External Braking Resistor Unit • Function: Provides a path to dissipate regenerative braking energy. • Includes: Internal DC brake chopper and an external, pre-selected braking resistor assembly. • Purpose: Enables controlled deceleration of high-inertia loads (large fans) and prevents drive overvoltage trips during stopping. Protection Features • Comprehensive motor thermal and electrical protection. • Drive overtemperature protection. • Braking resistor thermal protection (via +B055 unit). Application Focus Large Air Handling Units (AHUs), Centrifugal Chillers, Cooling Tower Fans, Large Industrial Pumps and Fans.

Key Specifications Parameter Category Specification Drive Series/Model ACS880-01-042A-7 Rated Output Current 42 A Rated Output Power 22 kW (30 HP) Input Supply Voltage 380 - 500 V AC (-15% / +10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Self-cooled (internal fan) Control Platform ABB Direct Torque Control (DTC) and Scalable Vector Control. Features a fully programmable platform with an optional Embedded PC (requires control program licenses). Key Standard Features • All-compatible Design: Single hardware platform for diverse applications. • Intelligent Control Panel (IOP): Graphical, multilingual, removable keypad for easy setup and diagnostics. • Extensive Built-in I/O: Includes multiple digital/analog inputs & outputs, and relay outputs for flexible connectivity. • Embedded Fieldbus Connectivity: Support for major industrial networks (e.g., PROFINET, EtherNet/IP, Modbus TCP, PROFIBUS DP) via optional communication adapter modules. • Application Software: A library of optional, pre-programmed software for pumps, fans, cranes, etc., to simplify commissioning. • Advanced Diagnostics & Safety: Comprehensive monitoring and supports optional safety functions (e.g., STO, SS1). Protection Features • Comprehensive motor thermal protection (I²t, PTC/KTY sensor inputs) • Full electrical protection (short circuit, ground fault, over/undervoltage, overcurrent) • Drive IGBT and heatsink overtemperature protection • Coated circuit boards available as an option for harsh environments. Application Focus Pumps, fans, conveyors, mixers, extruders, test benches, machine tools, and general industrial automation.
