Key Specifications Parameter Category Specification Drive Series/Base Model ACS880-01-430A-3 Rated Output Current 430 A Rated Output Power 200 kW (268 HP) Input Supply Voltage 380 - 415 V AC (-15% / +10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 Cooling Method Fan-cooled Control Platform ABB Direct Torque Control (DTC). Fully programmable. Key Standard Features • Intelligent Control Panel (IOP). • Extensive built-in I/O. • All-compatible application software options. Option +D150 Safe Torque Off (STO) & Safe Stop 1 (SS1) Safety Package • Functions: STO prevents unexpected startup; SS1 initiates a controlled stop before activating STO. • Safety Level: SIL 3 according to IEC 61800-5-2 / PL e according to ISO 13849-1. • Purpose: Allows direct connection to safety relays/PLCs for personnel protection during maintenance/intervention. Option +E200 Embedded PROFINET IO Controller/Device Adapter • Protocol: PROFINET IO (Conformance Class B/C). • Role: Supports Controller (for subordinate I/O) and Device (to a higher-level PLC) roles simultaneously. • Ports: 2 x RJ45 (100 Mbps), integrated switch. • Features: Supports IRT (Isochronous Real-Time), MRP (Media Redundancy Protocol), and PROFIsafe (for safety over PROFINET, complementing +D150). Protection Features • Comprehensive motor and drive electrical/thermal protection. • Integrated functional safety via +D150. Application Focus High-power, safety-critical, and networked automation: Automotive lines, Steel processing, Large material handling systems, Printing presses.

Key Specifications Parameter Category Specification Drive Series/Model DCS800-S01-0470-05 Motor Type DC Motor (Armature & Field Supply) Rated Armature Current 470 A (Continuous DC Output) Rated Power Output ~212 kW (284 HP) (for a typical 460V DC motor: 470A * 460V ≈ 216 kW). Power rating is voltage-dependent. Configuration Single Quadrant (S01): Forward motoring operation only. Cannot handle regenerative energy. Power Input Typically 3-phase, 400V AC (±10%), 50/60 Hz. (Confirm based on "-05" code). Armature Output Voltage Variable DC, typically up to ~500V DC for a 400V AC supply. Field Supply Output Separate, adjustable DC output for the motor's field winding (typically included). Control Method Digital control using thyristor (SCR) converter technology. Features current and speed feedback loops, programmable via DriveWindow software or control panel. Key Features • Digital Control Unit (DCU): Highly programmable for complex applications. • Precise Speed Regulation with tachometer or EMF feedback. • Torque Control capability. • Extensive I/O for process integration. • Field Weakening capability for extended speed range. • Diagnostic and monitoring functions. Protection Features • Armature and field overcurrent protection. • Motor thermal overload protection. • Mains phase loss and undervoltage protection. • Overvoltage and over-speed protection. • Heatsink overtemperature protection. Typical Applications Large extruders, Winders/Unwinders, Heavy mixers, Machine Tools, and other high-power machinery using DC motors where single-quadrant control is sufficient.

Key Specifications Parameter Category Specification Drive Series/Model ACS880-01-017A-3 Rated Output Current 17 A Rated Output Power 7.5 kW (10 HP) Input Supply Voltage 380 - 415 V AC (-15% / +10%), 3-phase (Typical for "-3" voltage code). Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Self-cooled (internal fan) Control Platform ABB Direct Torque Control (DTC) and Scalable Vector Control. Features a fully programmable platform with an optional Embedded PC (requires control program licenses). Key Standard Features • All-compatible Design: Single hardware platform for diverse applications. • Intelligent Control Panel (IOP): Graphical, multilingual, removable keypad for easy setup and diagnostics. • Extensive Built-in I/O: Includes multiple digital/analog inputs & outputs, and relay outputs for flexible connectivity. • Embedded Fieldbus Connectivity: Support for major industrial networks (e.g., PROFINET, EtherNet/IP, Modbus TCP, PROFIBUS DP) via optional communication adapter modules. • Application Software: A library of optional, pre-programmed software for pumps, fans, cranes, etc., to simplify commissioning. • Advanced Diagnostics & Safety: Comprehensive monitoring and supports optional safety functions (e.g., STO, SS1). Protection Features • Comprehensive motor thermal protection (I²t, PTC/KTY sensor inputs) • Full electrical protection (short circuit, ground fault, over/undervoltage, overcurrent) • Drive IGBT and heatsink overtemperature protection • Coated circuit boards available as an option for harsh environments. Application Focus Pumps, fans, conveyors, mixers, extruders, test benches, and general industrial automation.

Key Specifications Parameter Category Specification Drive Series/Model ACS580-04-650A-4 Configuration Modular (IP00), for cabinet installation ("Build-to-Order" frame). Rated Output Current 650 A Rated Output Power 315 kW (422 HP) (approximate, based on 400V, 3-phase). Input Supply Voltage 380 - 480 V AC (±10%), 3-phase, 50/60 Hz. Output Voltage/Phases 3-phase, 0 - Input voltage. Control Platform ABB Direct Torque Control (DTC). Key Hardware Features • High-Power Modular Design: Core inverter unit for custom cabinet integration. • Common DC Bus Ready: Can be connected to a shared DC bus system for regenerative energy sharing. • Requires External Cooling: Must be integrated with a forced-air cooling system (fans/air ducts) designed for the cabinet. • Requires External Control Interface: Needs a separate control unit (e.g., an external IOP or PLC interface) and control program. Protection Features • Motor thermal overload protection. • Short circuit, ground fault, over/undervoltage protection. • IGBT and heatsink overtemperature protection (via integrated sensors). Typical Mounting Vertically mounted on a heatsink/chassis inside a large industrial electrical cabinet. Application Focus High-power industrial fan and pump drives, heavy material handling, large compressor systems, and as part of multi-motor industrial processes.

Key Specifications Parameter Category Specification Drive Series/Model DCS550-S01-0225-05-00-00 Motor Type DC Motor (Armature & Field Supply) Rated Armature Current 225 A (Continuous DC Output) Rated Power Output ~98 kW (130 HP) (for a typical 460V DC motor: 225A * 460V ≈ 103.5 kW). Power rating is voltage-dependent. Configuration Single Quadrant (S01): Forward motoring operation only. Cannot handle regenerative energy. Power Input Typically 3-phase, 400V AC (±10%), 50/60 Hz. (Confirm based on "-05" code). Armature Output Voltage Variable DC, typically up to ~500V DC for a 400V AC supply. Field Supply Output Typically included in base unit (refer to manual). Adjustable DC output for the motor's field winding. Control Method Digital control using thyristor (SCR) converter technology. Features current and speed feedback loops, programmable via DriveWindow software or control panel. Key Features • Digital Control Unit (DCU): Programmable for complex applications. • Precise Speed Regulation with tachometer or EMF feedback. • Torque Control capability. • Extensive I/O for process integration. • Field Weakening capability for extended speed range. • Diagnostic and monitoring functions. Protection Features • Armature and field overcurrent protection. • Motor thermal overload protection. • Mains phase loss and undervoltage protection. • Overvoltage and over-speed protection. • Heatsink overtemperature protection. Typical Applications Extruders, Winders/Unwinders, Mixers, Machine Tools, Presses, and other heavy machinery using DC motors where single-quadrant control is sufficient.

Key Specifications Parameter Category Specification Drive Series/Model ACS150-03U-04A1-4 Rated Output Current 4.1 A Rated Output Power 1.5 kW (2 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Must be installed inside a protective control cabinet (e.g., IP20, IP54). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Ultra-Compact & Sealed Design: All-in-one unit with a durable keypad. • Easy Mounting: Snap-on design for DIN rail or screw mounting. • Application Macros: Pre-set configurations (e.g., Hand/Auto, 2-Wire, 3-Wire). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Digital Inputs: 3 channels. • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, miniature conveyors, packaging machinery, and other basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Model ACQ580-01-073A-4 Rated Output Current 73 A Rated Output Power 37 kW (50 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Topology Active Front End (AFE) / Regenerative Drive with IGBTs on both the input and output sides. Control Method ABB Direct Torque Control (DTC) Key Standard Features • Four-Quadrant Operation: Full motoring and regenerative braking capability. • Ultra-Low Harmonics: Input current THDi < 5% (meets IEEE 519-2014 without external filters). • Unity Power Factor: ~1.0 across the entire speed and load range. • Regeneration to Mains: Feeds braking energy back to the supply network, improving energy efficiency. • Intelligent Control Panel (IOP) with graphical display. • Common DC Bus Capable for multi-drive systems. Protection Features • Comprehensive motor and drive protection. • Mains phase loss and undervoltage protection. • Grid feedback protection (for reverse power conditions). Application Focus Applications with frequent braking or overhauling loads: Centrifuges, Cranes & Hoists, Downhill Conveyors, Test Benches, Wire Drawing Machines. Also for installations with strict harmonic limits.

Key Specifications Parameter Category Specification Drive Series/Model ACS150-03U-03A3-4 Rated Output Current 3.3 A Rated Output Power 0.75 kW (1 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Must be installed inside a protective control cabinet (e.g., IP20, IP54). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Ultra-Compact & Sealed Design: All-in-one unit with a durable keypad. • Easy Mounting: Snap-on design for DIN rail or screw mounting. • Application Macros: Pre-set configurations (e.g., Hand/Auto, 2-Wire, 3-Wire). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Digital Inputs: 3 channels. • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, miniature conveyors, packaging machinery, and other basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Model ACS150-03E-04A7-2 Rated Output Current 4.7 A Rated Output Power 1.1 kW (1.5 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating NEMA 1 / IP20 Open Type (Chassis). Must be installed inside a protective control cabinet. Control Panel Standard removable keypad (non-sealed). Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Removable Keypad: For flexible mounting on the cabinet door. • Flexible Mounting: DIN rail or screw mounting. • Application Macros: Pre-set parameter sets (Hand/Auto, 2-Wire, 3-Wire, etc.). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication available via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, conveyors, and basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS580-01-124A-4 Rated Output Current 124 A Rated Output Power 55 kW (75 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Energy Optimizer: Automatically minimizes energy losses. • Intelligent Control Panel (IOP): Multilingual graphical display. • Embedded Application Macros: For pumps, fans, etc. • Advanced PID Controller with sleep/wake. • Built-in Modbus RTU (RS-485). • Built-in EMC Filter (Class A). Option +K475 Embedded EtherNet/IP Adapter Module • Protocol: EtherNet/IP™ (CIP) Scanner/Adapter. • Ports: 2 x RJ45 (10/100 Mbps), switchable, with integrated network diagnostics (LEDs). • Function: Enables direct integration into EtherNet/IP networks for real-time control (I/O messaging) and configuration (explicit messaging). Supports cyclic and acyclic data exchange for seamless connectivity with Rockwell Automation PLCs (e.g., ControlLogix, CompactLogix) and other EtherNet/IP masters. Protection Features • Comprehensive motor thermal and electrical protection. • Drive IGBT overtemperature protection. Application Focus Pumps, fans, compressors, conveyors, and mixers within EtherNet/IP networked industrial plants, particularly those using Allen-Bradley control systems.

Key Specifications Parameter Category Specification Drive Series/Model ACS310-03U-17A2-4 Rated Output Current 17.2 A Rated Output Power 7.5 kW (10 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Methods • Scalar Control (V/f) • ABB Direct Torque Control (DTC) for superior performance. Key Standard Features • Intelligent Pump and Fan Control (IPF): Includes auto-tuning for energy optimization, multi-pump control logic, dry pump protection, and anti-jam. • Adaptive Program (AUP): Guides user through commissioning. • Built-in Communication Protocols: Modbus RTU (RS-485) and BACnet MS/TP are standard for building automation. • Integrated EMC Filter (Class A). • PID Controller: Advanced controller with sleep/wake and cascade control. • Embedded Application Programming: Basic function blocks for custom logic. Protection Features • Motor thermal overload protection (I²t) • Pump/Fan-specific protection (dry pump, overload, underload) • Short circuit, ground fault, overcurrent, overvoltage protection • IGBT overtemperature protection Application Focus HVAC systems (fans, pumps), pressure boosting, water supply, cooling towers

Key Specifications Parameter Category Specification Drive Series/Model ACS800-04M-0260-3+P901 Configuration Modular (IP00), for cabinet installation. Rated Output Current 260 A Rated Output Power 160 kW (215 HP) (at 400V, 3-phase) Input Supply Voltage 380 - 415 V AC (±10-15%), 3-phase, 50/60 Hz (Typical for "-3" voltage code). Output Voltage/Phases 3-phase, 0 - Input voltage. Control Platform ABB Direct Torque Control (DTC). Key Hardware Features • Modular Design: For flexible system integration. • Common DC Bus Ready: Can be connected to a shared DC bus system. • Built-in Diode Rectifier (in standard configuration). • Requires external cooling (fan/air duct) as per cabinet design. Option +P901 Standard Control Program with I/O Extension • Function: Provides the essential firmware and associated hardware (likely an I/O extension board) to make the drive operational. • Includes: Standard application software, extensive I/O capabilities (digital/analog inputs & outputs, relay outputs), and standard control features for speed and torque regulation. Communication Supports various fieldbus protocols (e.g., PROFIBUS DP, Modbus) via optional adapter modules . Protection Features • Motor thermal overload. • Short circuit, ground fault, over/undervoltage. • IGBT and heatsink overtemperature. Application Focus High-power industrial applications within multi-drive systems: Extruders, Conveyors, Large Pumps & Fans, Crushers, Test Benches.
