Key Parameters Category Description / Value Product Line Eaton BZM (Explosion-Proof Enclosures) Type Explosion-Proof Control Station / Operator Station Body Material Typically Cast Aluminum or other non-corrosive, non-sparking material. Hazardous Location Classifications Certified for Class I, Division 1, Class II, Division 1, and Class III groups (Exact certification must be verified from product documentation). Enclosure Rating Typically NEMA 4X (Weatherproof and Corrosion-Resistant) Control Devices Contains integrated control components (e.g., push buttons, switches, lights) as specified by the "U3N-3" code. Conduit Entries Multiple threaded openings for cable entry. Window / Cover Transparent, impact-resistant window for viewing indicators, with a bolted cover to maintain explosion-proof integrity.

Key Parameters Category Description / Value Product Line Eaton NZMN3 Accessories Compatible Breakers NZMN3 series air circuit breakers of the specified frame size (Frame 4). Function Undervoltage Release (UVR) Rated Control Supply Voltage (Us) 400-415V AC / 500V AC (as indicated by "A500" suffix). The exact voltage must be confirmed by the order code sticker on the device itself. Mounting Mounts directly onto the compatible NZMN3 breaker. Operation The breaker can only be closed when the supply voltage is present and above the trip threshold. It automatically trips when the voltage drops below the threshold or is lost.

Key Parameters Category Description / Value Product Line Eaton BZM Explosion-Proof Enclosures Type Explosion-Proof Control Station Rated Current 100 A Body Material Cast Aluminum Hazardous Location Class I Division 1, Class II Division 1, Class III Enclosure Rating NEMA 4X Protection Level IP66/IP67 Control Components May include push buttons, switches, indicators

Key Parameters Category Description / Value Product Line Eaton BZM Explosion-Proof Equipment Type Explosion-Proof Circuit Breaker Rated Current 80 A Number of Poles Typically 3-pole (to be confirmed from datasheet) Rated Voltage Up to 690V AC Breaking Capacity According to breaker specifications Body Material Cast Aluminum Hazardous Location Class I Division 1, Class II Division 1, Class III Enclosure Rating NEMA 4X Protection Level IP66/IP67 Standards IEC/EN 60079-0, IEC/EN 60079-1

Key Parameters Category Description / Value Product Line Eaton BZM Explosion-Proof Enclosures Type Explosion-Proof Junction Box Body Material Cast Aluminum Hazardous Location Class I Division 1, Class II Division 1, Class III Enclosure Rating NEMA 4X Protection Level IP66/IP67 Conduit Entries Multiple threaded openings Cover Bolted cover with sealing surface

Key Parameters Category Description / Value Product Line Eaton BZM (Explosion-Proof Enclosures) Type Explosion-Proof Junction Box Rated Current 32 A (for internal components/terminals) Body Material Typically Cast Aluminum or other non-corrosive, non-sparking material. Hazardous Location Classifications Certified for Class I, Division 1, Class II, Division 1, and Class III groups (Exact certification must be verified from product documentation). Enclosure Rating Typically NEMA 4X (Weatherproof and Corrosion-Resistant) Conduit Entries Multiple threaded openings (specific number and size defined by the "X1N-3" code). Cover Bolted cover with an integral sealing surface to maintain explosion-proof integrity. Internal Volume Specific internal cubic capacity for housing connections.

Key Parameters Category Description / Value Product Line Eaton 9SX UPS Series Type Online Double-Conversion UPS Rated Power Capacity 3000 VA / 3000 W Input • Voltage: 120 V AC • Connection: IEC connector (e.g., NEMA 5-15P) • Phase: 1-Phase Output • Voltage: 120 V AC • Connection: IEC outlets (e.g., (5) IEC 320 C13 outlets) • Phase: 1-Phase Topology Double-Conversion Online Typical Runtime Varies based on load; extended runtime available with external battery packs (EBM). Display/Interface LCD status display and control buttons. Communication USB, Serial, and optional network management card slot. Form Factor Tower

Key Parameters Category Description / Value Product Line Eaton FAZT (Fuse Switch Disconnectors) Rated Operational Current (Iₑ) 320 A (for the switch mechanism) Utilization Category AC-22B (for switching mixed resistive and inductive loads) or AC-23B (for switching motor loads) - Must be verified from datasheet. Rated Operational Voltage (Uₑ) Up to 690 V AC Rated Insulation Voltage (Uᵢ) 690 V / 1000 V Switch Function Load switching and isolation Protection Provided by external DIN-type fuses (e.g., 00 or 1 size, up to 320A) Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Screw terminals. Standards Compliance IEC/EN 60947-3

Key Parameters Category Description / Value Product Line Eaton NZM3 Accessories Compatible Breakers NZM3 Motor Protection Circuit Breakers (e.g., NZM3-XV... series) Function Analog Setting Digitization Module / Motor Drive Interface Input Reads the physical position of the breaker's analog setting potentiometers. Output Digital data representing the breaker's current settings. Communication Interface Typically requires connection to a System Interface (SI) module (e.g., XV-SI) for integration into a network (e.g., Profibus, DeviceNet, Modbus-TCP). Mounting Designed to be mounted directly onto the compatible NZM3 breaker. Purpose • Setting Read-back: Allows a control system to read the actual protection settings configured on the breaker. • Condition Monitoring: Verifies that the settings have not been manually changed without the control system's knowledge. • Documentation: Provides digital documentation of protection parameters.

Key Parameters Category Description / Value Product Line Eaton DILM (Contactor) & Accessories (Timer) Compatible Contactor DILM115C Contactor Rated Operational Current (Iₑ) at AC-3 115 A (For squirrel-cage motors) Contactor Rated Operational Power at AC-3 ~ 55 kW / 75 HP at 400V 50Hz Contactor Poles 3 (Main Contacts) Contactor Coil Control Voltage DC - The specific voltage (e.g., 24V, 110V DC) must be confirmed by the order code sticker on the contactor itself. Module Type Timer Module Timer Function Specific function (e.g., On-delay, Off-delay, Star-Delta) as defined by "GC" code. Module Power Supply Derived from the main contactor coil circuit. Mounting Snap-on mounting directly onto the DILM115C contactor. Standards Compliance IEC/EN 60947-4-1

Key Parameters Category Description / Value Product Line Eaton PL (Miniature Circuit Breakers) Rated Current (Iₙ) 16 A Number of Poles Typically available in 1-Pole, 2-Pole, 3-Pole, and 4-Pole versions Tripping Characteristic D-Curve (Instantaneous trip between 10-20 x Iₙ) Rated Operational Voltage (Uₑ) 230/400 V AC Rated Insulation Voltage (Uᵢ) 500 V Breaking Capacity According to IEC/EN 60898 standard (typically 10 kA) Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Screw terminals

Key Parameters Category Description / Value Product Line Eaton PL (Miniature Circuit Breakers) Rated Current (Iₙ) 25 A Number of Poles Typically available in 1-Pole, 2-Pole, 3-Pole, and 4-Pole versions Tripping Characteristic D-Curve (Instantaneous trip between 10-20 x Iₙ) Rated Operational Voltage (Uₑ) 230/400 V AC Rated Insulation Voltage (Uᵢ) 500 V Breaking Capacity According to IEC/EN 60898 standard (typically 10 kA) Standards Compliance IEC/EN 60898-1 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail) Connection Screw terminals
