ABB

Technical Specifications: Output Current: 4.1A Voltage Range: 380-480V AC (±10%), 3-phase Power Rating: 1.5kW (at 400V) Control Method: Flux-optimized DTC control Overload Capacity: 110% continuous, 150% for 60 seconds Efficiency: >97% (typical) Enclosure Rating: IP21 (NEMA 1) Cooling Method: Fan cooled Operating Temperature: 0°C to +40°C (full output), up to +50°C with derating Dimensions: 172 x 245 x 195mm (WxHxD) Key Features: ✔ Intuitive Operation: Built-in multilingual control panel with LCD display Assisted start-up wizard for easy commissioning Parameter copy function between drives ✔ Flexible Connectivity: Standard Modbus RTU communication Optional fieldbus adapters (Profibus, Ethernet/IP) 2 analog inputs (0/4-20mA or 0-10V) 3 digital inputs, 2 relay outputs ✔ Comprehensive Protection: Motor thermal protection Overcurrent/overvoltage protection Earth fault detection Short circuit protection Certifications & Compliance: CE, UL, cUL RoHS compliant Meets IEC 61800-5-1 safety standards

557

ABB

Key Specifications Output Current: 3.4A Voltage Range: 380–480V AC (±10%), 3-phase Power Rating: 1.1kW (at 400V) Control Method: Flux-optimized DTC (Direct Torque Control) Overload Capacity: 110% continuous, 150% for 60 sec Efficiency: >97% (typical) Enclosure Rating: IP21 (NEMA 1, fan-cooled) Operating Temp: 0°C to +40°C (up to +50°C with derating) Advanced Features ✔ User-Friendly Operation: Built-in LCD control panel (multilingual interface) Assisted start-up wizard for quick commissioning Copy function for easy parameter transfer ✔ Smart Connectivity: Standard Modbus RTU (RS-485) Optional fieldbus adapters (Profibus, Ethernet/IP) 2 analog & 3 digital inputs, 2 relay outputs ✔ Protection & Safety: Motor thermal protection Short-circuit & overvoltage protection Safe Torque Off (STO, optional) Certifications & Compliance CE, UL, cULus RoHS compliant IEC 61800-5-1 (safety standards)

846

ABB

Key Specifications Output Current: 2.7A Voltage Range: 380–480V AC (±10%), 3-phase Power Rating: 0.75kW (at 400V) Control Method: Flux-optimized DTC (Direct Torque Control) Overload Capacity: 110% continuous, 150% for 60 sec Efficiency: >97% (typical) Enclosure Rating: IP21 (NEMA 1, fan-cooled) Operating Temp: 0°C to +40°C (up to +50°C with derating) Advanced Features ✔ User-Friendly Operation: Built-in LCD control panel (multilingual interface) Assisted start-up wizard for quick commissioning Copy function for easy parameter transfer ✔ Smart Connectivity: Standard Modbus RTU (RS-485) Optional fieldbus adapters (Profibus, Ethernet/IP) 2 analog & 3 digital inputs, 2 relay outputs ✔ Protection & Safety: Motor thermal protection Short-circuit & overvoltage protection Safe Torque Off (STO, optional) Certifications & Compliance CE, UL, cULus RoHS compliant IEC 61800-5-1 (safety standards)

869

ABB

Technical Specifications: Output Current: 45A Voltage Range: 380-480V AC (±10%), 3-phase Power Range: 22-30kW (depending on voltage) Control Technology: Direct Torque Control (DTC) Overload Capacity: 150% for 60 seconds Efficiency: >98% typical Cooling Method: Air cooling (standard) Protection Class: IP00 (cabinet installation required) Key Features: ✔ Advanced Control Performance: ±0.1% speed accuracy (with encoder) Full torque at zero speed Built-in PID controller ✔ Smart Connectivity: Multiple fieldbus options (Profibus, Modbus, Ethernet/IP) Integrated safety functions (STO, SS1) Condition monitoring capabilities ✔ Robust Design: -40°C to +55°C operating range (with derating) Low harmonic distortion Compact footprint Certifications & Compliance: CE, UL, cULus IEC 61800-5-1 compliant EMC Directive 2014/30/EU

899

ABB

Technical Specifications: Output Current: 62A Voltage Range: 380-480V AC (±10%), 3-phase Power Rating: 30kW (at 400V) Control Method: Flux-optimized DTC control Overload Capacity: 110% continuous, 150% for 60 seconds Efficiency: >97% (typical) Key Features: ✔ User-Friendly Operation: Built-in multilingual control panel Assisted start-up wizard Copy function for parameter settings ✔ Connectivity Options: Standard Modbus RTU Optional fieldbus adapters (Profibus, Ethernet/IP) 2 analog & 3 digital inputs, 2 relay outputs ✔ Protection Functions: Motor thermal protection Overcurrent/overvoltage protection Earth fault detection Short circuit protection Physical Specifications: Enclosure Rating: IP21 (NEMA 1) Cooling Method: Fan cooled Operating Temperature: 0°C to +40°C (full output) Up to +50°C with derating Dimensions: 245 x 405 x 220mm (WxHxD) Certifications & Compliance: CE, UL, cUL RoHS compliant Meets IEC 61800-5-1 safety standards

440

ABB

Technical Specifications: Output Current: 414A Voltage Range: 380-500V AC, 3-phase (±10%) Power Range: 250-315kW (voltage dependent) Control Technology: Advanced Direct Torque Control (DTC) Overload Capacity: 150% for 60 seconds Efficiency: >98% (typical full-load) Cooling Method: Liquid or forced air cooling (configurable) Protection Class: IP00 (requires cabinet installation) Key Features: ✔ Superior Control Performance: ±0.1% speed accuracy (with encoder) Full torque production at zero speed Built-in adaptive PID controller ✔ Advanced Connectivity: Multiple fieldbus options (Profibus, Ethernet/IP, Modbus) Integrated safety functions (STO, SS1, SLS) Condition monitoring capabilities ✔ Robust Construction: Designed for 24/7 operation -40°C to +55°C operating range (with derating) Low harmonic distortion design Certifications & Compliance: CE, UL, cULus listed IEC 61800-5-1 compliant Meets EMC Directive 2014/30/EU

880

ABB

Key Specifications Output Current: 246A Voltage Range: 380–480V AC (±10%), 3-phase Power Range: 132–160kW (depending on voltage) Control Method: Direct Torque Control (DTC) Overload Capacity: 150% for 60 seconds Efficiency: >98% (typical) Cooling Options: Air or liquid cooling (configurable) Protection Class: IP00 (cabinet installation required) Advanced Features ✔ Precision Control: ±0.1% speed accuracy (with encoder feedback) Full torque at zero speed Built-in PID controller for process automation ✔ Smart Connectivity & Safety: Multiple fieldbus options (Profibus DP, Modbus RTU, Ethernet/IP) Integrated Safe Torque Off (STO) for functional safety Predictive maintenance via condition monitoring ✔ Robust & Reliable: Wide operating temperature range (-40°C to +55°C with derating) Heavy-duty design for 24/7 industrial use Low harmonic distortion with optional filters Certifications & Compliance CE, UL, cULus IEC 61800-5-1 (safety standards) EMC compliant (2014/30/EU)

329

ABB

Key Specifications: Rated Output: Current: 88A Voltage: 380-480V AC, 3-phase Power: 45kW (at 400V) Control Characteristics: Flux-optimized DTC control Speed range: 1:100 (without encoder) Torque boost capability Standard Features: ✔ User Interface: Integrated control panel with LCD display Multilingual menu navigation ✔ Connectivity: Built-in Modbus RTU Optional fieldbus adapters (Profibus, Ethernet/IP) 2 analog & 3 digital inputs, 2 relay outputs ✔ Protection Functions: Motor thermal protection Overcurrent/overvoltage protection Earth fault detection Physical Specifications: Enclosure: IP21 (NEMA 1) Cooling: Fan cooled Ambient Temperature: 0°C to +40°C (full output) Up to +50°C with derating Dimensions: 278 x 460 x 235mm (WxHxD) Certifications & Compliance: CE, UL, cUL RoHS compliant Meets IEC 61800-5-1

914

ABB

Key Specifications: Drive Module: ACS880-01-363A-3 Output current: 363A Voltage range: 380-480V AC (±10%) Power range: 200-250kW (depending on voltage) Enclosure: D150 Protection class: IP21 (standard) Cooling method: Forced air cooling Built-in disconnect switch Technical Features: ✔ Advanced Control: DTC (Direct Torque Control) technology 0.1 Hz speed control without encoder ±0.3% speed accuracy ✔ System Integration: Multiple fieldbus options (Profibus, Modbus, Ethernet/IP) Built-in EMC filter Integrated brake chopper (optional) ✔ Protection & Safety: STO (Safe Torque Off) safety function Overload capacity: 150% for 60 seconds Short circuit protection Environmental Specifications: Operating temperature: 0°C to +40°C Storage temperature: -40°C to +70°C Relative humidity: <95% (non-condensing) Altitude: Up to 1000m without derating Certifications: CE, UL, cUL, EAC Complies with IEC 61800-5-1

903

ABB

Key Specifications: Power Rating: 246A output current Voltage Class: 380-480V AC, 3-phase Power Range: 132-160kW (depends on voltage) Control Technology: DTC (Direct Torque Control) Enclosure Type: IP00 (cabinet installation) Communication Protocols: • Standard: Modbus RTU • Optional: Profibus DP, Ethernet/IP, DeviceNet Protection Features: • Overcurrent/overvoltage protection • Motor thermal protection • Short circuit protection Cooling Method: Liquid or air cooling (configurable) Ambient Temperature: 0°C to +40°C (up to +50°C with derating) Certifications: CE, UL, cUL Features: • True industrial-grade reliability for 24/7 operation • Integrated safety functions (STO, SS1) • Advanced heat management system • Modular design for easy maintenance • Compatible with ABB drive system accessories

303

ABB

Key Features & Specifications 1. Power & Performance Output Current: 363 A Rated Power: ~250–315 kW (depends on motor voltage, e.g., 315 kW at 400V, 250 kW at 500V) Input Voltage: 380–500V AC (±10%), 3-phase, 50/60 Hz Output Frequency: 0–500 Hz (adjustable) 2. Motor Control Technology ABB Direct Torque Control (DTC) – Provides high torque accuracy (±0.1%) without needing an encoder (sensorless operation). Supports induction (IM) & permanent magnet (PM) motors. Dynamic braking (with optional brake resistor for deceleration control). 3. Compact & Robust Design Wall-mounted (IP21 enclosure) – Saves panel space while protecting against dust and dripping water. Forced air cooling (built-in fan) for stable operation under heavy loads. Modular design – Easy maintenance with plug-in I/O and optional expansion modules. 4. Smart Connectivity & Integration Built-in Ethernet & fieldbus support (PROFIBUS, Modbus, CANopen via optional adapters). ABB Ability™ compatible – Enables remote monitoring, predictive maintenance, and data analytics. Drive Composer PC tool – Simplifies parameter tuning, diagnostics, and firmware updates. 5. Safety & Protection Safe torque-off (STO) – SIL3-certified safety function to prevent unintended starts. Overload, short-circuit, and overheating protection – Ensures long-term reliability. CE, UL, cUL, and IEC 61800-5-1 compliance – Meets global industry standards.

267

ABB

Key Features & Specifications: Power & Performance Rated Power: 450 kW (603 HP) Output Current: Depends on voltage (e.g., ~780A at 400V, ~390A at 690V) Input Voltage: 380–690V AC, 3-phase, 50/60Hz Output Frequency: 0–300 Hz (configurable) Advanced Motor Control Direct Torque Control (DTC): Ensures fast torque response (±0.1% speed accuracy) without needing an encoder (sensorless control). Supports induction motors (IM) and synchronous motors (SM). Energy Efficiency & Savings Regenerative braking capability (with optional brake chopper/unit). Optimized for IE3/IE4 high-efficiency motors, reducing energy consumption. Robust Design & Cooling Air-cooled (IC 411) or liquid-cooled (LC) options available. Enclosure: IP21 (standard) or IP54 (optional) for dust/moisture protection. Smart Connectivity & Control Fieldbus Protocols: PROFIBUS, Modbus, CANopen, Ethernet/IP (via optional adapters). ABB Drive Composer: PC tool for parameterization, monitoring, and diagnostics. PLC Embedded Control (optional, reducing external hardware needs). Protection & Safety Built-in safeguards: Overcurrent, overvoltage, motor overload, short-circuit, and ground fault protection. Complies with CE, UL, cUL, and IEC standards.

256
